Danfoss VLT 6000 series User Manual

VLT
®
6000 HVAC Series
Installation
■ Mains supply 3 x 525-600 V
According to international requirements VLT type 6102 6122
Output current I
VLT,N
[A] (525-550 V) 113 137
I
VLT, MAX
(60 s) [A] (525-550 V) 124 151
I
VLT,N
[A] (551-600 V) 108 131
I
VLT, MAX
(60 s) [A] (551-600 V) 119 144
Output S
VLT,N
[kVA] (550 V) 108 131
S
VLT,N
[kVA] (575 V) 108 130
Typical shaft output [kW] (550 V) 75 90
[HP] (575 V) 100 125
Max. cable cross-section to motor
[mm
2
]
4,5
[AWG]
2,4,5
2x70
2x2/0
Max. cable cross-section to
loadsharing and brake
[mm
2
]
4,5
[AWG]
2,4,5
2x70
2x2/0
Rated input current I
L,N
[A] (550 V) 110 130
I
L,N
[A] (575 V) 106 124
I
L,N
[A] (690 V) 109 128
Max. cable cross-section
power supply
[mm
2
]
4,5
[AWG]
2,4,5
2x70
2x2/0
Min. cable cross-section to motor and
power supply
[mm
2
]
4,5
[AWG]
2,4,5
35
2
Min. cable cross-section to brake and
loadsharing
[mm
2
]
4,5
[AWG]
2,4,5
10
8
Max. pre-fuses (mains) [-]/UL [A]
1
200 250
Efficiency
3
0.98
Power loss [W] 2156 2532
Weight IP 00 [kg] 82
Weight IP 21/Nema1 [kg] 96
Weight IP 54/Nema12 [kg] 96
Enclosure IP 00, IP 21/Nema 1 and IP 54/Nema12
1. For type of fuse see section Fuses
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
4. Max. cable cross-section is the maximum possible cable cross-section allowed to be fitted on
the terminals. Min. cable cross-section is the minimum allowed cross-section. Always comply
with national and local regulations on min. cable cross-section.
5. Connection bolt 1 x M10 / 2 x M10 (mains and motor), connection bolt 1 x M8 / 2 x M8 (DC-bus).
