VLT
®
8000 AQUA
Programming
NB!:
If Sum or Relative is selected, one of the
preset references will always be active. If the
preset references are to be without influence,
they should be set to 0% (as in the factory setting)
via the serial communication port.
211 Preset reference 1
(PRESET REF. 1)
212 Preset reference 2
(PRESET REF. 2)
213 Preset reference 3
(PRESET REF. 3)
214 Preset reference 4
(PRESET REF. 4)
Value:
-100.00 % - +100.00 %
✭ 0.00%
of the reference range/external reference
Function:
Four different preset references can be programmed
in parameters 211-214 Preset reference. The preset
reference is stated as a percentage value of the
reference range (Ref
MIN
-Ref
MAX
) or as a percentage
of the other external references, depending on the
choice made in parameter 210 Reference type.
The choice between the preset references can
be made by activating terminal 16, 17, 29, 32
or 33, cf. the table below.
Terminal 17/29/33 Terminal 16/29/32
preset ref. msb preset ref. lsb
0 0 Preset ref. 1
0 1 Preset ref. 2
1 0 Preset ref. 3
1 1 Preset ref. 4
Description of choice:
Set the required preset reference(s) that is/are
to be the options.
215 Current limit, I
LIM
(CURRENT LIMIT)
Value:
0.1 - 1.1 x I
VLT,N
✭ 1.0 x I
VLT,N
[A]
Function:
This is where the maximum output current I
LIM
is set.
The factory setting corresponds to the rated output
current. If the current limit is to be used as motor
protection, the rated motor current must be set. If
the current limit is set within the range of 1.0-1.1
xI
VLT,N
(the rated output current of the frequency
converter), the frequency converter can only handle
a load intermittently, i.e. for short periods at a time.
After the load has been higher than I
VLT,N
,itmustbe
ensured that for a period the load is lower than I
VLT,N
.
Please note that if the current limit is set to
less than I
VLT,N
, the acceleration torque will be
reduced correspondingly.
Description of choice:
Set the required maximum output current I
LIM
.
216 Frequency bypass, bandwidth
(FREQUENCY BYPASS B.W)
Value:
0 (OFF) - 100 Hz
✭ Disable
Function:
Some systems call for some output frequencies
to be avoided because of mechanical resonance
problems in the system. These output frequencies can
be programmed in parameters 217-220 Frequency
bypass. In this parameter (216 Frequency bypass,
bandwidth), a definition can be given of a bandwidth
around each of these frequencies.
Description of choice:
The bypass bandwidth is equal to the programmed
bandwidth frequency. This bandwidth will be centered
around each bypass frequency.
217 Frequency bypass 1
(BYPASS FREQ. 1)
218 Frequency bypass 2
(BYPASS FREQ. 2)
219 Frequency bypass 3
(BYPASS FREQ. 3)
220 Frequency bypass 4
(BYPASS FREQ. 4)
Value:
0 - 120 HZ
✭ 120.0 Hz
Function:
Some systems call for some output frequencies
to be avoided because of mechanical resonance
problems in the system.
Description of choice:
Enter the frequencies to be avoided.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
