VLT
®
8000 AQUA
504 DC brake
(DC BRAKE)
Value:
Digital input (DIGITAL INPUT)
[0]
Serial communication (SERIAL PORT)
[1]
Logic and (LOGIC AND)
[2]
✭Logic or (LOGIC OR)
[3]
Function:
See functional description under parameter
503 Coasting.
Description of choice:
The table below shows when the motor is running and is
DC-braking when Digital input [0], Serial communication
[1], Logic and [2] or Logic or [3] has been selected.
NB!:
PleasenotethatDC braking inverse [3] via
terminal 19, terminal 27 and bit 03 of the control
word is active in the case of logic ’0’.
Digital input [0] Serial communication [1]
Serial Serial
Term.
19/27
com.Function
Term.
19/27
com.Function
0 0 DC-brake 0 0 DC-brake
0 1 DC-brake 0 1 Motor run.
1 0 Motor run. 1 0 DC-brake
1 1 Motor run. 1 1 Motor run.
Logic and [2] Logic or [3]
Serial Serial
Term.
19/27
com.Function Term.
19/27
com.Function
0 0 DC-brake 0 0 DC-brake
0 1 Motor run. 0 1 DC-brake
1 0 Motor run. 1 0 DC-brake
1 1 Motor run. 1 1 Motor run.
505 Start
(START)
Value:
Digital input (DIGITAL INPUT)
[0]
Serial communication (SERIAL PORT)
[1]
Logic and (LOGIC AND)
[2]
✭Logic or (LOGIC OR)
[3]
Function:
See functional description under parameter
503 Coasting.
Description of choice:
The table below shows when the motor has stopped
and gives the situations in which the frequency
converter has a start command when Digital input
[0], Serial communication [1], Logic and [2] or
Logic or [3] has been selected.
Digital input [0] Serial communication [1]
Serial Serial
Kl.18 com. Function
Kl.18 com. Function
0 0 Stop 0 0 Stop
0 1 Stop 0 1 Start
1 0 Start 1 0 Stop
1 1 Start 1 1 Start
Logic and [2] Logic or [3]
Serial Serial
Kl.18 com. Function Kl.18 com. Function
0 0 Stop 0 0 Stop
0 1 Stop 0 1 Start
1 0 Stop 1 0 Start
1 1 Start 1 1 Start
506 Reversering
(REVERSING)
Value:
✭Digital input (DIGITAL INPUT)
[0]
Serial communication (SERIAL PORT)
[1]
Logic and (LOGIC AND)
[2]
Logic or (LOGIC OR)
[3]
Function:
See functional description under parameter
503 Coasting.
Description of choice:
The table below shows when the motor is running
clockwise and anti-clockwise when Digital input
[0], Serial communication [1], Logic and [2] or
Logic or [3] has been selected.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.83.A2.02 - VLT is a registered Danfoss trademark
160
