Danfoss VLT 8000 AQUA series User Manual

VLT
®
8000 AQUA
Introduction
Mainssupply3x690V
VLT
Rated Current at 690
V
Max. output
frequency (Hz)
Power
dissipation (W)
Ordering no. IP00
Ordering no.
IP20
8052 54 60 290 130B2223 130B2258
8062 73 60 390 130B2225 130B2260
8072 86 60 480 130B2225 130B2260
8102 108 60 600 130B2226 130B2261
8122 131 60 550 130B2228 130B2263
8152 155 60 680 130B2228 130B2263
8202 192 60 920 130B2229 130B2264
8252 242 60 750 130B2231 130B2266
8302 290 60 1000 130B2231 130B2266
8352 344 60 1050 130B2232 130B2267
8402 400 60 1150 130B2234 130B2269
8502 530 60 500 130B2241 130B2270
8602 600 60 570 130B2242 130B2271
8652 630 60 600 - -
dU/dt filters
The dU/dt filters reduce dU/dt to approx. 500 V / µsec. These filters do not red
uce noise or Upeak.
NB!:
When using dU/dt filters, the switching
frequency must be 1.5 kHz (see parameter 411)
Mains supply3x690V
VLT
Rated Current at 690
V
Max. output
frequency (Hz)
Power
dissipation (W)
Ordering no. IP 00
Ordering no.
IP20
8052 54 60 90 130B2154 130B2188
8062 73 60 100 130B2155 130B2189
8072 86 60 110 130B2156 130B2190
8102 108 60 120 130B2157 130B2191
8122 131 60 150 130B2158 130B2192
8152 155 60 180 130B2159 130B2193
8202 192 60 190 130B2160 130B2194
8252 242 60 210 130B2161 130B2195
8302 290 60 350 130B2162 130B2196
8352 344 60 480 130B2163 130B2197
8402 400 60 540 130B2165 130B2199
8502 530 60 500 130B2236 130B2239
8602 600 60 570 130B2237 130B2240
8652 630 60 600 - -
MG.83.A2.02 - VLT is a registered Danfoss trademark
19
