Danfoss VLT 8000 AQUA series User Manual

VLT
®
8000 AQUA
■ Ordering numbers, LC filter modules
Mains supply 3 x 200 - 240 V
LC filter LC filter Rated current Max. output Power
for VLT type enclosure at 200 V frequency loss Order no.
8006-8008 IP 00 25.0 A 60 Hz 110 W 175Z4600
8011 IP 00 32 A 60 Hz 120 W 175Z4601
8016 IP 00 46 A 60 Hz 150 W 175Z4602
8022 IP 00 61 A 60 Hz 210 W 175Z4603
8027 IP 00 73 A 60 Hz 290 W 175Z4604
8032 IP 00 88 A 60 Hz 320 W 175Z4605
8042 IP 00 115 A 60 Hz 600 W 175Z4702
8052 IP 00 143 A 60 Hz 600 W 175Z4702
8062 IP 00 170 A 60 Hz 700 W 175Z4703
Mainssupply3x380-480
LC filter LC filter Rated current Max. output Power
for VLT type enclosure at 400/480 V frequency loss Order no.
8006-8011 IP 20 16 A / 16 A 120 Hz 175Z0832
8016 IP 00 24 A/ 21.7 A 60 Hz 170 W 175Z4606
8022 IP 00 32 A / 27.9 A 60 Hz 180 W 175Z4607
8027 IP 00 37.5 A / 32 A 60 Hz 190 W 175Z4608
8032 IP 00 44 A / 41.4 A 60 Hz 210 W 175Z4609
8042 IP 00 61 A / 54 A 60 Hz 290 W 175Z4610
8052 IP 00 73 A / 65 A 60 Hz 410 W 175Z4611
8062 IP 00 90 A / 78 A 60 Hz 480 W 175Z4612
8072 IP 20 106 A / 106 A 60 Hz 500 W 175Z4701
8102 IP 20 147 A / 130 A 60 Hz 600 W 175Z4702
8122 IP 20 177 A / 160 A 60 Hz 750 W 175Z4703
8152 IP 20 212 A / 190 A 60 Hz 750 W 175Z4704
8202 IP 20 260 A / 240 A 60 Hz 900 W 175Z4705
8252 IP 20 315 A / 302 A 60 Hz 1000 W 175Z4706
8302 IP 20 395 A / 361 A 60 Hz 1100 W 175Z4707
8352 IP 20 480 A / 443 A 60 Hz 1700 W 175Z3139
8452 IP 20 600 A / 540 A 60 Hz 2100 W 175Z3140
8502 IP 20 658 A / 590 A 60 Hz 2100 W 175Z3141
8602 IP 20 745 A / 678 A 60 Hz 2500 W 175Z3142
Regarding LC filters for 525 - 600 V and VLT 8652,
380-480 V, please contact Danfoss.
NB!:
When using LC filters, the switching frequency
must be 4.5 kHz (see parameter 407).
For VLT 8452-8602 parameter 408 must be set to
LC filter fitted to obtain proper operation.
MG.83.A2.02 - VLT is a registered Danfoss trademark
18
