Danfoss VLT 8000 AQUA series User Manual

VLT
®
8000 AQUA
All about VLT 8000
AQUA
■ Factory settings
PNU
#
Parameter
description
Factory setting Range Changes
during
operation
4-setup Con-
ver-
sion
index
Data
type
201 Output frequency low limit, f
MIN
0.0 Hz 0.0 - f
MAX
Yes Yes -1 6
202 Output frequency, f
MAX
60 Hz/ 50 Hz f
MIN
-120 Hz Yes Yes -1 6
203 Reference site Hand/Auto linked
reference
Yes Yes 0 5
204 Minimum Ref ence, Ref
MIN
0.000 0.000-par. 100 Yes Yes -3 4
205 Maximum Ref ence, Ref
MAX
60 Hz/ 50 Hz par. 100-999.999,999 Yes Yes -3 4
206 Ramp-up time Depends on the unit 1 - 3600 Yes Yes 0 7
207 Ramp-down time Depends on the unit 1 - 3600 Yes Yes 0 7
208 Automatic ramp-up/down Enable Yes Yes 0 5
209 Jog frequency 10.0 Hz 0.0 - par. 100 Yes Yes -1 6
210 Reference type Preset reference/
Sum
Yes Yes 0 5
211 Preset Reference 1 0.00 % -100.00 - 100.00 % Yes Yes -2 3
212 Preset Reference 2 0.00 % -100.00 - 100.00 % Yes Yes -2 3
213 Preset Reference 3 0.00 % -100.00 - 100.00 % Yes Yes -2 3
214 Preset Reference 4 0.00 % -100.00 - 100.00 % Yes Yes -2 3
215 Current limit, I
LIM
1.0 x I
VLT
[A] 0,1-1,1 x I
VLT
,[A] Yes Yes -1 6
216 Frequency bypass, bandwidth 0Hz 0-100Hz Yes Yes 0 6
217 Frequency bypass 1 120 Hz f
MIN
-120 Hz Yes Yes -1 6
218 Frequency bypass 2 120 Hz f
MIN
-120 Hz Yes Yes -1 6
219 Frequency bypass 3 120 Hz f
MIN
-120 Hz Yes Yes -1 6
220 Frequency bypass 4 120 Hz f
MIN
-120 Hz Yes Yes -1 6
221 Warning: Low current, I
LOW
0.0 A 0.0 - par. 222 Yes Yes -1 6
222 Warning: Higth current, I
HIGH
I
VLT,MAX
Par. 221 - I
VLT,MAX
Yes Yes -1 6
223 Warning: Low frequency f
LOW
0.0 Hz 0.0 - par. 224 Yes Yes -1 6
224 Warning: High frequency f
HIGH
120.0 Hz Par. 223 - par. 202
(f
MAX
)
Yes Yes -1 6
225 Warning: Low reference Ref
LOW
-999,999.999 -999,999.999 - par.
226
Yes Yes -3 4
226 Warning: Low reference High
HIGH
999,999.999 Par. 225 - 999,999.999 Yes Yes -3 4
227 Warning: Low feedback FB
LOW
-999,999.999 -999,999.999 - par.
228
Yes Yes -3 4
228 Warning: High feedback FB
HIGH
999,999.999 Par. 227 - 999,999.999 Yes Yes -3 4
229 Initial ramp OFF 000.1-360.0 s No Yes -1 6
230 Fill rate OFF 000000.001-
999999.999
Yes Yes -3 7
231 Filled setpoint Par. 413 Par. 413 to par. 205 Yes Yes -3 4
) Global factory setting different from North American factory setting.
Changes during operation:
"Yes" means that the parameter can be changed,
while the frequency converter is in operation. "No"
means that the frequency converter must be stopped
before a change can be made.
4
-Setup:
"Yes" means that the parameter can be programmed
individually in each of the four setups, i.e. the
same parameter can have four different
data
values. "No" means that the data value will be
the same in all four setups.
C
onversion index:
This number refers to a conversion figure to be
used when writing or reading to or from a frequency
converter by means of serial communication.
MG.83.A2.02 - VLT is a registered Danfoss trademark
197
