Introduction
525-600 V
Typecode
Position in string
T6
9-10
C00
11-13
C20
11-13
CN1
11-13
ST
14-15
R0
16-17
1.1 kW/1.5 HP 8002 XXX X
1.5 kW/2.0 HP 8003 XXX X
2.2 kW/3.0 HP 8004 XXX X
3.0 kW/4.0 HP 8005 XXX X
4.0 kW/5.0 HP 8006 XXX X
5.5 kW/7.5 HP 8008 XXX X
7.5 kW/10 HP 8011 XXX X
11 kW/15 HP 8016 X X X
15 kW/20 HP 8022 X X X
18.5 kW/25 HP 8027 X X X
22 kW/30 HP 8032 X X X
30 kW/40 HP 8042 X X X
37 kW/50 HP 8052 X X X
45 kW/60 HP 8062 X X X
55 kW/75 HP 8072 X X X
525-690 V
Typecode
Position in string
T7
9-10
C00
11-13
CN1
11-13
C54
11-13
ST
11-13
EX
11-13
DX
14-15
PS
14-15
PD
14-15
PF
14-15
R0
16-17
R1
16-17
1)
45 kW/50 HP 8052 XXXX X X XX X XX
55 kW/60 HP 8062 XXXX X X XX X XX
75 kW/75 HP 8072 XXXX X X XX X XX
90 kW/100 HP 8102 XXXX X X XXX XX
110 kW/125 HP 8122 XXXX X X XXXXX
132 kW/150 HP 8152 XXXX X X XXXXX
160 kW/200 HP 8202 XXXX X X XXXXX
200 kW/250 HP 8252 XXXX X X XXXXX
250 kW/300 HP 8302 XXXX X X XXXXX
315 kW/350 HP 8352 XXXX X X XXXXX
400 kW/400 HP 8402 XXXX X X XXXXX
500 kW/400 HP 8502 XXXX X X XXXX
560 kW/500 HP 8602 XXXX X X XXXX
630 kW/600 HP 8652 XXXX X X XXXX
1) R1 is not available with DX, PF and PD variants.
T7: 525-690 VAC
C00: Compact IP 00
C20: Compact IP 20
CN1: Compact NEMA 1
ST: Standard
R0: Without filter
R1: Class A1 filter
NB!:
NEMA 1 exceeds IP 20
