Danfoss VLT 8000 AQUA series User Manual

VLT
®
8000 AQUA
Installation
Cable lengths and cross-sections:
Max. motor cable length, screened cable ........................................................................................... 150m/500 ft
Max. motor cable length, unscreened cable ..................................................................................... 300m/1000 ft
Max. motor cable length, screened cable VLT 8011 380-480 V .......................................................... 100m/330 ft
Max. motor cable length, screened cable VLT 8011 525-600 V ............................................................ 50m/164 ft
Max. DC-bus cable length, screened cable .................................... 25m/82 ft from frequency converter to DC bar.
Max. cable cross-section to motor, see next section
Max. cross-section for 24 V external DC supply ........................................................................ 2.5 mm
2
/12 AWG
Max. cross-section for control cables ........................................................................................ 1.5 mm
2
/16 AWG
Max. cross-section for serial communication ............................................................................. 1.5 mm
2
/16 AWG
If UL/cUL is to be complied with, copper cable with temperature class 60/75°C / 140/167°F must be used
(VLT 8002 - 8072 (525 - 600 V), VLT 8006 - 8072 (380 - 480 V) and VLT 8002 - 8032 (200 - 240V). If
UL/cUL is to be complied with, copper cable with temperature class 75°C/167°F must be used (VLT 8102
- 8652 (380 - 480 V), VLT 8042 - 8062 (200 - 240 V), VLT 8052 - 8652 (525-690 V)).
Connectors are for use of both copper and aluminium cables, unless other is specified.
Control characteristics:
Frequency range .................................................................................................................................... 0 - 120 Hz
Resolution on output frequency ............................................................................................................. ±0.003 Hz
System response time ............................................................................................................................... 3 msec.
Speed, control range (open loop) ..................................................................................... 1:100 of synchro. speed
Speed, accuracy (open loop) .............................................................................. < 1500 rpm:max. error ± 7.5 rpm
> 1500 rpm: max. error of 0.5% of actual speed
Process, accuracy (closed loop) ......................................................................... < 1500 rpm: max.error ± 1.5 rpm
> 1500 rpm: max. error of 0.1% of actual speed
All control characteristics are based on a 4-pole asynchronous motor
Accuracy of display readout (parameters 009-012 Display readout):
Motor current, 0 - 140% load ................................................................. Max. error: ±2.0% of rated output current
Power kW, Power HP, 0 - 90% load ........................................................ Max. error: ±5.0% of rated output power
MG.83.A2.02 - VLT is a registered Danfoss trademark
33
