■ Technical data, mains supply 3 x 380 - 480 V
According to international requirements VLT type 8152 8202 8252 8302 8352
Output
current
I
VLT,N
[A] (380-440 V) 212 260 315 395 480
I
VLT, MAX
(60 s) [A] (380-440 V) 233 286 347 435 528
I
VLT,N
[A] (441-480 V) 190 240 302 361 443
I
VLT, MAX
(60 s) [A] (441-480 V) 209 264 332 397 487
Output
power
S
VLT,N
[kVA] (400 V) 147 180 218 274 333
S
VLT,N
[kVA] (460 V) 151 191 241 288 353
Typical shaft output (380-440 V) P
VLT,N
[kW] 110 132 160 200 250
Typical shaft output (441-480 V) P
VLT,N
[HP] 150 200 250 300 350
Max. cable cross-section to motor and
DC-bus [mm
2
]
2) 4) 5)
2x70 2x70 2x185 2x185 2x185
Max. cable cross-section to motor and
DC-bus [AWG]
2) 4) 5)
2x2/0
mcm
2x2/0
mcm
2x350
mcm
2x350
mcm
2x350
mcm
Min. cable cross-section to motor and
DC-bus [mm
2
/AWG]
2) 4) 5)
35/2 35/2 35/2 35/2 35/2
Max. input
current
I
L,N
[A] (380 V) 208 256 317 385 467
(RMS) I
L,N
[A] (480 V) 185 236 304 356 431
Max. cable cross-section to power [mm
2
]
2)
4) 5)
2x70 2x70 2x185 2x185 2x185
Max. cable cross-section to power [AWG]
2)
4) 5)
2x2/0
mcm
2x2/0
mcm
2x350
mcm
2x350
mcm
2x350
mcm
Max. pre-
fuses
[-]/UL
1)
[A] 300/300 350/350 450/400 500/500 630/600
Weight
IP 00/
Chassis
[kg/lbs] 82/181 91/201 112/247 123/271 138/304
Weight
IP 20/
NEMA 1
[kg/lbs] 96/212 104/229 125/276 136/300 151/333
Weight
IP 54/
NEMA 12
[kg/lbs] 96/212 104/229 125/276 136/300 151/333
Efficiency at rated frequency 0.98
Power loss
at max.
load.
[W] 2619 3309 4163 4977 6107
Enclosure IP 00/Chassis/IP 21/NEMA 1/IP 54/NEMA 12
1. For type of fuse, see section Fuses.
2. American Wire Gauge.
3. Measured using 30 m/100 ft screened motor cables at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals. Max. cable
cross section is the maximum possible cable cross section that can be fitted on the terminals.
Always comply with national and local regulations on min. cable cross-section.
5. Connection bolt 1 x M10 / 2 x M10 (mains and motor), connection bolt 1 x M8 / 2 x M8 (DC-bus).
