DOWN
DOWN DOWN
DOWN
R/L1 91
S/L2 92
FASTENER TORQUE: M10 19 NM (14 FT-LB
T/L3 93
FASTENER TORQUE: M8 9.6 NM (7 FT-LB)
FASTENER TORQUE: M8 9.6 NM (7 FT-LB)
FASTENER TORQUE: M1019 NM (14 FT-LB)
-DC 88
+DC 89
-R 81
+R 82
U/T1 96
V/T2 97
W/T3 98
130BB015.10
1
2
3
4
6
7
8
9
10
5
Illustration 3.55 Compact IP21 (NEMA 1) and IP54 (NEMA 12),
Enclosure Type D1
130BB016.10
R/L1 91
S/L2 92
T/L3 93
FASTENER
TORQUE.
M10 19 NM (14 FT-LB)
1
2
3
4
5
6
7
8
9
10
FASTENER TORQUE:
FASTENER TORQUE: M10 19 NM (7 FT-LB)
FASTENER TORQUE:
-DV 88
-R 81
+R 82
U/T1 96
V/T2 97
W/T3 98
+DC 89
M8 9.6 NM (7 FT-LB)
M8 9.6 NM (7 FT-LB)
Illustration 3.56 Compact IP21 (NEMA 1) and IP54 (NEMA 12)
with Disconnect, Fuse and RFI Filter, Enclosure Type D2
1)
AUX Relay 5) Brake
01 02 03 -R +R
04 05 06 81 82
2) Temp Switch 6) SMPS Fuse (see fuse tables for part number)
106 104 105 7) AUX Fan
3) Mains 100 101 102 103
R S T L1 L2 L1 L2
91 92 93 8) Fan Fuse (see fuse tables for part number)
L1 L2 L3 9) Mains ground
4) Load sharing 10) Motor
-DC +DC U V W
88 89 96 97 98
T1 T2 T3
Table 3.17 Legend to Illustration 3.55 and Illustration 3.56
