0-20 Display Line 1.1 Small
Option: Function:
[953] Profibus Warning
Word
Displays Profibus communication
warnings.
[1005] Readout Transmit
Error Counter
View the number of CAN control
transmission errors since the last
power-up.
[1006] Readout Receive
Error Counter
View the number of CAN control
receipt errors since the last power-up.
[1007] Readout Bus Off
Counter
View the number of Bus Off events
since the last power-up.
[1013] Warning
Parameter
View a DeviceNet-specific warning
word. One separate bit is assigned to
every warning.
[1230] Warning
Parameter
[1500] Operating hours View the number of running hours of
the frequency converter.
[1501] Running Hours View the number of running hours of
the motor.
[1502] kWh Counter View the mains power consumption
in kWh.
[1580] Fan Running
Hours
[1600] Control Word View the Control Word sent from the
frequency converter via the serial
communication port in hex code.
[1601] Reference [Unit] Total reference (sum of digital/analog/
preset/bus/freeze ref./catch up and
slow-down) in selected unit.
[1602] Reference [%] Total reference (sum of digital/analog/
preset/bus/freeze ref./catch up and
slow-down) in percent.
[1603] Status Word Present status word
[1605] Main Actual Value
[%]
One or more warnings in a Hex code
[1609] Custom Readout View the user-defined readouts as
defined in 0-30 Custom Readout Unit,
0-31 Custom Readout Min Value and
0-32 Custom Readout Max Value.
[1610] Power [kW] Actual power consumed by the motor
in kW.
[1611] Power [hp] Actual power consumed by the motor
in hp.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Frequency Motor frequency, i.e. the output
frequency from the frequency
converter in Hz.
[1614] Motor current Phase current of the motor measured
as effective value.
0-20 Display Line 1.1 Small
Option: Function:
[1615] Frequency [%] Motor frequency, i.e. the output
frequency from the frequency
converter in percent.
[1616] Torque [Nm] Present motor load as a percentage
of the rated motor torque.
[1617] Speed [RPM] Speed in RPM (revolutions per
minute) i.e. the motor shaft speed in
closed loop based on the entered
motor nameplate data, the output
frequency and the load on the
frequency converter.
[1618] Motor Thermal Thermal load on the motor, calculated
by the ETR function. See also
parameter group 1-9* Motor
Temperature.
[1622] Torque [%] Shows the actual torque produced, in
percentage.
[1630] DC Link Voltage Intermediate circuit voltage in the
frequency converter.
[1632] Brake Energy /s Present brake power transferred to an
external brake resistor.
Stated as an instantaneous value.
[1633] Brake Energy /2
min
Brake power transferred to an
external brake resistor. The mean
power is calculated continuously for
the most recent 120 seconds.
[1634] Heatsink Temp. Present heat sink temperature of the
frequency converter. The cut-out limit
is 95 ±5 °C; cutting back in occurs at
70 ±5 °C.
[1635] Inverter Thermal Percentage load of the inverters
[1636] Inv. Nom. Current Nominal current of the frequency
converter
[1637] Inv. Max. Current Maximum current of the frequency
converter
[1638] SL Controller
State
State of the event executed by the
control
[1639] Control Card
Temp.
Temperature of the control card.
[1650] External
Reference
Sum of the external reference as a
percentage, i.e. the sum of analog/
pulse/bus.
[1652] Feedback[Unit] Signal value in units from the
programmed digital input(s).
[1653] Digi Pot
Reference
View the contribution of the digital
potentiometer to the actual reference
Feedback.
How to programme the freque... VLT AQUA Drive FC 202 Operation Instructions
MG20P402 - Rev. 2013-12-16 85
5 5
