4 = far right inverter module in F14 frame size.
5 = rectier module.
6 = right rectier module in F14 frame size.
ALARM 244, Heatsink temperature
This alarm is only for F-frame adjustable frequency drives.
It is equivalent to Alarm 29. The report value in the alarm
log indicates which power module generated the alarm.
1 = left most inverter module.
2 = middle inverter module in F12 or F3 frame
sizes.
2 = right inverter module in F10 or F11 frame
sizes.
2 = second adjustable frequency drive from the
left inverter module in F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left inverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectier module.
6 = right rectier module in F14 frame size.
ALARM 245, Heatsink sensor
This alarm is only for F-frame adjustable frequency drives.
It is equivalent to Alarm 39. The report value in the alarm
log indicates which power module generated the alarm.
1 = left most inverter module.
2 = middle inverter module in F12 or F13 frame
sizes.
2 = right inverter module in F10 or F11 frame
sizes.
2 = second adjustable frequency drive from the
left inverter module in F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left inverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectier module.
6 = right rectier module in F14 frame size.
ALARM 246, Power card supply
This alarm is only for F-frame adjustable frequency drive. It
is equivalent to Alarm 46. The report value in the alarm log
indicates which power module generated the alarm.
1 = left most inverter module.
2 = middle inverter module in F12 or F13 frame
sizes.
2 = right inverter module in F10 or F11 frame
sizes.
2 = second adjustable frequency drive from the
left inverter module in F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left inverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectier module.
6 = right rectier module in F14 frame size.
ALARM 247, Power card temperature
This alarm is only for F-frame adjustable frequency drives.
It is equivalent to Alarm 69. The report value in the alarm
log indicates which power module generated the alarm.
1 = left most inverter module.
2 = middle inverter module in F12 or F13 frame
sizes.
2 = right inverter module in F10 or F11 frame
sizes.
2 = second adjustable frequency drive from the
left inverter module in F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
3 = third from the left inverter module in F14
frame size.
4 = far right inverter module in F14 frame size.
5 = rectier module.
6 = right rectier module in F14 frame size.
ALARM 248, Illegal power section conguration
This alarm is only for F-frame adjustable frequency drives.
It is equivalent to Alarm 79. The report value in the alarm
log indicates which power module generated the alarm:
1 = left most inverter module.
2 = middle inverter module in F12 or F13 frame
sizes.
2 = right inverter module in F10 or F11 frame
sizes.
2 = second adjustable frequency drive from the
left inverter module in F14 frame size.
3 = right inverter module in F12 or F13 frame
sizes.
Status Messages
VLT
®
AutomationDrive FC 302 Low Harmonic Drive
132–630 kW
76 Danfoss A/S © Rev. 04/2015 All rights reserved. MG37A322
