Danfoss VLT AutomationDrive FC 300 Series Installation Manual

No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter Reference
40 Overload of digital output terminal 27 (X) 5-00, 5-01
41 Overload of digital output terminal 29 (X) 5-00, 5-02
46 Pwr. card supply X X
47 24 V supply low X X X
48 1.8 V supply low X X
65 Control board overtemperature X X X
66 Heatsink temperature low X
67 Option conguration has changed X
68 Safe torque o activated
X
1)
69 Pwr. card temp X X
70 Illegal FC conguration X
72 Dang. failure
X
1)
73 Safe torque o auto restart
76 Power unit set-up X
79 Illegal PS cong X X
80 Unit initialized to default value X
244 Heatsink temp X X X
245 Heatsink sensor X X
246 Pwr.card supply X X
247 Pwr.card temp X X
248 Illegal PS cong X X
250 New spare part X
251 New type code X X
300 Mains cont. fault X
301 SC cont. fault X
302 Cap. overcurrent X X
303 Cap. ground fault X X
304 DC overcurrent X X
305 Mains freq. limit X
308 Resistor temp X X
309 Power ground fault X X
311 Switch. freq. limit X
312 CT range X
314 Auto CT interrupt X
315 Auto CT error X
316 CT location error X
317 CT polarity error X
318 CT ratio error X
Table 7.2 Alarm/Warning Code List
A trip is the action when an alarm has appeared. The trip coasts the motor and can be reset by pressing [Reset] or make a
reset by a digital input (parameter group 5-1* Digital Inputs [1] Reset). The original event that caused an alarm cannot
damage the adjustable frequency drive or cause dangerous conditions. A trip lock is an action that occurs in conjunction
with an alarm, which may cause damage to the adjustable frequency drive or connected parts. A trip lock situation can only
be reset by power cycling.
