Illustration 5: Visual Representation of a D10h Enclosure and the Locations of Available Options
Passive harmonic filter (PHF)
Line reactor
Non-fusible disconnect
Fusible disconnect
Molded-case circuit breaker (MCCB)
Mains contactor
dU/dt filter
Common-mode filter
Sine-wave filter
Drive module (varies in power rating)
AQ262139143212en-000301 / 130R0879 | 21Danfoss A/S © 2021.10
Product Overview
VLT® AutomationDrive FC 302
Operating Guide
