Mains connector frame size A4/A5 (IP 55/66)
When disconnector is used (frame size A4/A5) the PE must be mounted on the left side of the drive.
Illustration 3.3: Mains connection frame sizes B1 and B2 (IP
21/NEMA Type 1 and IP 55/66/ NEMA Type 12).
Illustration 3.4: Mains connection size B3 (IP20).
