10 How to Order a Drive
10.1 Drive Congurator
F
C
-
T
e30bh108.11
X
S
A
B
X
X
X
X
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
30
22
21
23
27
25
24
26
28
29
31
32
X
3 6 1 4 E 2 0 H 2 X X C X
X
Table 10.1 Type Code String
Product group
1–6
Model
7–10
Mains Voltage
11–12
Enclosure
13–15
Hardware conguration
16–23
RFI lter
16–17
Brake
18
Display (LCP)
19
PCB coating
20
Mains option
21
Adaptation A
22
Adaptation B
23
Software release
24–27
Software language
28
A options
29–30
B options
31–32
Table 10.2 Type Code Example for Ordering a Drive
Congure the correct drive for the proper application by
using the internet-based drive congurator. The drive
congurator is found on the global internet site:
www.danfoss.com/drives. The congurator creates a type
code string and an 8-digit sales number, which can be
delivered to the local sales oce. It is also possible to
build a project list with several products and send it to a
Danfoss sales representative.
An example of a type code string is:
FC-361N132T4E20H2XXCXXXSXXXXA0BX
The meaning of the characters in the string is
dened in
this chapter. In the example above, a drive is congured
with the following options:
•
RFI lter, Class A2.
•
3C3.
•
PROFIBUS DP-V1.
Drives are delivered automatically with English and
Chinese languages.
