9.7.10 Figure 10 - 917CM17
130BD256.10
14
8
175Uxxxx
6
3
4
45 [1.8]
235 [9.3]
160 [6.3]
85 [3.3]
30 [1.2]
30 [1.2]
Illustration 9.49 IP20, Side View, Right
1 Resistor
2
Terminal board, see Illustration 9.52
3 Cable gland for load cables
4 Cable gland M16 temperature switch cable
5 Grounding bolt M6
6 Name plate/warning signs
7 Front cover IP20
8 Rear cover IP20
9 Top cover IP20
10
Temperature switch 260 °C (NC)
11 Load connection, 2x bolt M8
12 Auxiliary connection for temperature switch, porcelain
clamp 2.5 mm
2
13 4x fixing hole Ø 9 mm
14 Second cable gland. Not in use.
Table 9.19 Legend to Illustration 9.49 to Illustration 9.53
Danfoss P/N Type code
Resistance
[Ω]
Cable gland type for load terminals Weight [kg]
175u3072 MCE101C7R40P11K0E20BAW 7.4 M40 24
175u3075 MCE101C6R10P13K0E20BAW 6.1 M50 25
175u3083 MCE101C3R70P11K0E20BAW 3.7 M50 24
175u3084 MCE101C3R30P13K0E20BAW 3.3 2xM25 25
175u3201 MCE101C27R0P14K0E20BAW 27.0 M25 25
175u3204 MCE101C19R0P14K0E20BAW 19 M25 25
175u3206 MCE101C14R0P14K0E20BAW 14.0 M32 25
175u3224 MCE101C3R50P14K0E20BAW 3.5 M40 25
Table 9.20 Mechanical Dimensions
260°C
1
2
The
rmocontact
260 °C (NC)
712[28.0]
740[29.1]
13
2
5
7
1
10
4
3
5
13
130BD257.10
Illustration 9.50 IP20, Front View
130BD248.10
380 [ 15.0 ]
300 [ 11.8 ]
480 [ 18.9 ]
13
7
Illustration 9.51 IP20, Side View, Left
Specifications Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 107
9 9
