Danfoss VLT Brake Resistor MCE 101 User Manual

10% duty cycle, horizontal braking, T4
FC 102 Horizontal braking 10% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T4 1.1 546 607.3 630 0.100 175u3002 - - - 1.5 0.4
T4 1.5 382 437.3 410 0.100 175u3004 - - - 1.5 0.5
T4 2.2 260 293.3 270 0.200 175u3007 - - - 1.5 0.8
T4 3 189 212.7 200 0.200 175u3008 - - - 1.5 0.9
T4 4 135 157.3 145 0.300 175u3300 - - - 1.5 1.3
T4 5.5 99.0 113.3 110 0.450 175u3335 175u3450 175u3449 - 1.5 1.9
T4 7.5 72.0 82.4 80 0.570 175u3336 175u3452 175u3451 - 1.5 2.5
T4 11 50.0 55.3 56 0.680 175u3337 175u3027 175u3028 - 1.5 3.3
T4 15 36.0 40.3 38 1.130 175u3338 175u3034 175u3035 - 1.5 5.2
T4 18.5 27.0 32.5 28 1.400 175u3339 175u3039 175u3040 - 1.5 6.7
T4 22 20.3 27.2 22 1.700 175u3340 175u3047 175u3048 - 1.5 8.3
T4 30 18.0 19.8 19 2.200 175u3357 175u3049 175u3050 - 1.5 10.1
T4 37 13.4 16.0 14 2.800 175u3341 175u3055 175u3056 - 2.5 13.3
T4 45 10.8 13.1 12 3.200 175u3359 175u3061 175u3062 - 2.5 15.3
T4 55 8.8 10.7 9.5 4.200 - 175u3065 175u3066 - 4 20
T4 75 6.5 7.8 7.0 5.500 - 175u3070 175u3071 - 6 26
T4 90 4.2 6.5 5.5 7.000 - - - 175u3231 10 36
T4 110 3.6 5.3 4.7 9.000 - - - 175u3079 16 44
T4 132 3.0 4.4 3.7 11.000 - - - 175u3083 25 55
T4 160 2.5 3.6 3.3 13.000 - - - 175u3084 35 63
T4 200 2.0 2.9 2.7 16.000 - - - 175u3088 50 77
T4 250 1.6 2.3 2.1 20.000 - - - 175u3091 70 98
T4 315 1.2 1.8 1.7 26.000 - - - 175u3093 2x35 124
T4 355 1.2 1.6 1.3 32.000 - - - 175u3097 2x35 157
T4 400 1.2 1.4 1.2 36.000 - - - 175u3098 2x50 173
T4 450 1.1 1.3 1.1 42.000 - - - 175u3099 2x50 196
T4 500 0.9 1.1 2x1.9 - - - - - - -
T4 560 0.9 1.0 2x1.7 - - - - - - -
T4 630 0.8 0.9 2x1.5 - - - - - - -
T4 710 0.7 0.8 2x1.3 - - - - - - -
T4 800 0.6 0.7 3x1.8 - - - - - - -
T4 1000 0.5 0.6 3x1.6 - - - - - - -
Table 8.5 T4, Horizontal Braking 10% Duty Cycle
Selection Guide Design Guide
36 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
88
