40% duty cycle, vertical braking, T4
FC 102 Vertical braking 40% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T4 1.1 546 607.3 630 0.300 175u3309 - - - 1.5 0.7
T4 1.5 382 437.3 410 0.450 175u3310 175u3416 175u3415 - 1.5 1
T4 2.2 260 293.3 270 0.570 175u3311 175u3418 175u3417 - 1.5 1.4
T4 3 189 212.7 200 0.960 175u3312 175u3420 175u3419 - 1.5 2.1
T4 4 135 157.3 145 1.130 175u3313 175u3422 175u3421 - 1.5 2.7
T4 5.5 99.0 113.3 110 1.700 175u3314 175u3424 175u3423 - 1.5 3.7
T4 7.5 72.0 82.4 80 2.200 175u3315 175u3138 175u3139 - 1.5 5
T4 11 50.0 55.3 56 3.200 175u3316 175u3428 175u3427 - 1.5 7.1
T4 15 36.0 40.3 38 5.000 - - - 175u3236 1.5 11.5
T4 18.5 27.0 32.5 28 6.000 - - - 175u3237 2.5 14.7
T4 22 20.3 27.2 22 8.000 - - - 175u3238 4 19
T4 30 18.0 19.8 19 10.000 - - - 175u3203 4 23
T4 37 13.4 16.0 14 14.000 - - - 175u3206 10 32
T4 45 10.8 13.1 12 17.000 - - - 175u3210 10 38
T4 55 8.8 10.7 9.5 21.000 - - - 175u3213 16 47
T4 75 6.5 7.8 7.0 26.000 - - - 175u3216 25 61
T4 90 4.2 6.5 5.5 36.000 - - - 175u3219 35 81
T4 110 3.6 5.3 4.7 42.000 - - - 175u3221 50 95
T4 132 3.0 4.4 3.7 52.000 - - - 175u3223 70 119
T4 160 2.5 3.6 3.3 60.000 - - - 175u3225 2x35 135
T4 200 2.0 2.9 2.7 78.000 - - - 175u3228 2x50 170
T4 250 1.6 2.3 2.1 90.000 - - - 175u3230 2x70 207
T4 315 1.2 1.8 1.7 - - - - - - -
T4 355 1.2 1.6 1.3 - - - - - - -
T4 400 1.2 1.4 1.2 - - - - - - -
T4 450 1.1 1.3 1.1 - - - - - - -
T4 500 0.9 1.1 2x1.9 - - - - - - -
T4 560 0.9 1.0 2x1.7 - - - - - - -
T4 630 0.8 0.9 2x1.5 - - - - - - -
T4 710 0.7 0.8 2x1.3 - - - - - - -
T4 800 0.6 0.7 3x1.8 - - - - - - -
T4 1000 0.5 0.6 3x1.6 - - - - - - -
Table 8.6 T4, Vertical Braking 40% Duty Cycle
Selection Guide Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 37
8 8
