Danfoss VLT Brake Resistor MCE 101 User Manual

10% duty cycle, horizontal braking, T7
FC 102 Horizontal braking 10% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T7 1.1 620 830 630 0.100 175u3002 - - - 1.5 0.4
T7 1.5 513 600 570 0.100 175u3003 - - - 1.5 0.4
T7 2.2 340 403 415 0.200 175u3005 - - - 1.5 0.7
T7 3 243 292 270 0.300 175u3361 - - - 1.5 1
T7 4 180 216 200 0.360 - 175u3009 175u3010 - 1.5 1.3
T7 5.5 130 156 145 0.450 - 175u3012 175u3013 - 1.5 1.7
T7 7.5 94 113 105 0.790 - 175u3481 175u3482 - 1.5 2.6
T7 11 94.5 110.9 105 0.790 175u3360 175u3481 175u3482 - 1.5 2.7
T7 15 69.7 80.7 72 1.130 175u3351 175u3466 175u3465 - 1.5 3.8
T7 18.5 46.8 65.1 52 1.400 175u3352 175u3468 175u3467 - 1.5 4.9
T7 22 36.0 54.5 42 1.700 175u3353 175u3032 175u3033 - 1.5 6
T7 30 29.0 39.7 31 2.200 175u3354 175u3470 175u3469 - 1.5 7.9
T7 37 22.5 32.1 27 2.800 175u3355 175u3472 175u3471 - 2.5 9.6
T7 45 18.0 26.3 22 3.200 175u3356 175u3479 175u3480 - 2.5 11.3
T7 55 13.5 21.4 15.5 4.200 - 175u3474 175u3473 - 4 15.4
T7 75 13.5 15.6 13.5 5.500 - 175u3476 175u3475 - 6 19
T7 90 8.8 13.0 11 7.000 - - - 175u3232 10 25
T7 110 8.8 10.6 9.1 9.000 - - - 175u3067 16 32
T7 132 6.6 8.8 7.4 11.000 - - - 175u3072 16 39
T7 160 4.2 7.2 6.1 13.000 - - - 175u3075 16 46
T7 200 4.2 5.8 5.0 16.000 - - - 175u3078 25 57
T7 250 3.4 4.6 4.0 20.000 - - - 175u3082 35 71
T7 315 2.3 3.7 3.2 26.000 - - - 175u3085 50 90
T7 400 2.3 2.9 2.5 32.000 - - - 175u3089 70 113
T7 450 2.0 2.6 2.3 36.000 - - - 175u3090 2x35 125
T7 500 1.9 2.3 2.0 42.000 - - - 175u3092 2x35 145
T7 560 1.5 2.1 1.6 52.000 - - - 175u3094 2x50 180
T7 630 1.4 1.8 1.4 60.000 - - - 175u3095 2x50 207
T7 710 1.2 1.6 2x2.6 - - - - - - -
T7 800 1.1 1.4 2x2.2 - - - - - - -
T7 900 1.0 1.3 2x2.0 - - - - - - -
T7 1000 0.9 1.1 3x2.6 - - - - - - -
T7 1200 0.8 1.0 3x2.4 - - - - - - -
T7 1400 0.6 0.8 3x2.0 - - - - - - -
Table 8.9 T7, Horizontal Braking 10% Duty Cycle
Selection Guide
Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 39
8 8
