40% duty cycle, vertical braking, T7
FC 102 Vertical braking 40% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T7 1.1 620 830 630 0.360 - 175u3108 175u3109 - 1.5 0.8
T7 1.5 513 600 570 0.570 - 175u3110 175u3111 - 1.5 1
T7 2.2 340 403 415 0.790 - 175u3112 175u3113 - 1.5 1.3
T7 3 243 292 270 1.130 - 175u3118 175u3119 - 1.5 2
T7 4 180 216 200 1.700 - 175u3122 175u3123 - 1.5 2.8
T7 5.5 130 156 145 2.200 - 175u3106 175u3107 - 1.5 3.7
T7 7.5 94 113 105 3.200 - 175u3132 175u3133 - 1.5 5.2
T7 11 94.5 110.9 105 4.200 - 175u3134 175u3135 - 1.5 6
T7 15 69.7 80.7 72 4.200 - 175u3142 175u3143 - 1.5 7.2
T7 18.5 46.8 65.1 52 6.000 - - - 175u3242 2.5 10.8
T7 22 36.0 54.5 42 8.000 - - - 175u3243 2.5 13.9
T7 30 29.0 39.7 31 10.000 - - - 175u3244 4 18
T7 37 22.5 32.1 27 14.000 - - - 175u3201 10 23
T7 45 18.0 26.3 22 17.000 - - - 175u3202 10 28
T7 55 13.5 21.4 15.5 21.000 - - - 175u3205 16 37
T7 75 13.5 15.6 13.5 26.000 - - - 175u3209 16 44
T7 90 8.8 13.0 11 36.000 - - - 175u3212 25 57
T7 110 8.8 10.6 9.1 42.000 - - - 175u3214 35 68
T7 132 6.6 8.8 7.4 52.000 - - - 175u3215 50 84
T7 160 4.2 7.2 6.1 60.000 - - - 175u3218 70 99
T7 200 4.2 5.8 5.0 78.000 - - - 175u3220 2x35 125
T7 250 3.4 4.6 4.0 90.000 - - - 175u3222 2x35 150
T7 315 2.3 3.7 3.2 - - - - - - -
T7 400 2.3 2.9 2.5 - - - - - - -
T7 450 2.0 2.6 2.3 - - - - - - -
T7 500 1.9 2.3 2.0 - - - - - - -
T7 560 1.5 2.1 1.6 - - - - - - -
T7 630 1.4 1.8 1.4 - - - - - - -
T7 710 1.2 1.6 2x2.6 - - - - - - -
T7 800 1.1 1.4 2x2.2 - - - - - - -
T7 900 1.0 1.3 2x2.0 - - - - - - -
T7 1000 0.9 1.1 3x2.6 - - - - - - -
T7 1200 0.8 1.0 3x2.4 - - - - - - -
T7 1400 0.6 0.8 3x2.0 - - - - - - -
Table 8.10 T7, Vertical Braking 40% Duty Cycle
Selection Guide
Design Guide
40 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
