P/N
Resi-
stance
Continuous
power 100%
load
Pulse
load
power
10%
duty
cycle
1)
Pulse
load
power
40%
duty
cycle
1)
Temp.
switch
2)
3)
Terminal max wire
cross-section
Wire cross-section
4)
Temp. switch Power cables Temp. switch Power cables
[Ω]
[W] [kW] [kW] Type
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
175U3058 13.5 4200 52.5 14.8 1 4.0 12 55 1/0 - - - -
175U3059 13 680 9.4 2.2 1 4.0 12 16 6 - - - -
175U3060 13 680 9.4 2.2 1 4.0 12 16 6 - - - -
175U3061 12 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3062 12 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3063 11 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3064 11 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3065 9.5 4200 52.5 14.8 1 4.0 12 55 1/0 - - - -
175U3066 9.5 4200 52.5 14.8 1 4.0 12 55 1/0 - - - -
175U3067 9.1 9000 121 29 2 2.5 14 2xM8 - - - -
175U3068 9.0 1130 14.5 3.1 1 4.0 12 16 6 - - - -
175U3069 9.0 1130 14.5 3.1 1 4.0 12 16 6 - - - -
175U3070 7.0 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3071 7.0 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3072 7.4 11000 148 36 2 2.5 14 2xM8 - - - -
175U3073 5.7 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3074 5.7 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3075 6.1 13000 174 42 2 2.5 14 2xM8 - - - -
175U3076 5.5 6300 87.0 20.5 1 6.0 10 55 1/0 - - - -
175U3077 5.5 6300 87.0 20.5 1 6.0 10 55 1/0 - - - -
175U3078 5.0 16000 215 52 2 2.5 14 2xM8 - - - -
175U3079 4.7 9000 121 29 2 2.5 14 2xM8 - - - -
175U3080 3.5 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3081 3.5 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3082 4.0 20000 268 65 2 2.5 14 2xM8 - - - -
175U3083 3.7 11000 148 36 2 2.5 14 2xM8 - - - -
175U3084 3.3 13000 174 42 2 2.5 14 2xM8 - - - -
175U3085 3.3 26000 349 85 2 2.5 14 2xM8 - - - -
175U3086 2.8 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3087 2.8 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3088 2.7 16000 215 52 2 2.5 14 2xM8 - - - -
175U3089 2.5 32000 429 104 2 2.5 14 2xM8 - - - -
175U3090 2.3 36000 483 117 2 2.5 14 2xM8 - - - -
175U3091 2.1 20000 268 65 2 2.5 14 2xM8 - - - -
175U3092 2.0 42000 563 137 2 2.5 14 2xM8 - - - -
175U3093 1.7 26000 349 85 2 2.5 14 2xM8 - - - -
175U3094 1.6 52000 697 169 2 2.5 14 2xM8 - - - -
175U3095 1.4 60000 805 195 2 2.5 14 2xM8 - - - -
175U3096 300 200 3.05 0.75 1 - - - - 0.5 20 1.5 16
175U3097 1.3 32000 429 104 2 2.5 14 2xM8 - - - -
175U3098 1.2 36000 483 117 2 2.5 14 2xM8 - - - -
175U3099 1.1 42000 563 137 2 2.5 14 2xM8 - - - -
175U3101 1200 200 3.05 0.75 1 - - - - 0.5 20 1.5 16
175U3102 1200 360 4.2 1.05 1 4.0 12 16 6 - - - -
175U3103 1200 360 4.2 1.05 1 4.0 12 16 6 - - - -
175U3104 850 280 2.8 0.7 1 4.0 12 16 6 - - - -
175U3105 850 280 2.8 0.7 1 4.0 12 16 6 - - - -
175U3106 145 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3107 145 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3108 630 360 4.2 1.05 1 4.0 12 16 6 - - - -
175U3109 630 360 4.2 1.05 1 4.0 12 16 6 - - - -
175U3110 570 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3111 570 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3112 415 790 9.5 2.37 1 4.0 12 16 6 - - - -
175U3113 415 790 9.5 2.37 1 4.0 12 16 6 - - - -
175U3114 410 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3115 410 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3116 270 790 9.5 2.37 1 4.0 12 16 6 - - - -
175U3117 270 790
9.5 2.37
1 4.0 12 16 6 - - - -
Specifications Design Guide
68 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
