P/N
Resi-
stance
Continuous
power 100%
load
Pulse
load
power
10%
duty
cycle
1)
Pulse
load
power
40%
duty
cycle
1)
Temp.
switch
2)
3)
Terminal max wire
cross-section
Wire cross-section
4)
Temp. switch Power cables Temp. switch Power cables
[Ω]
[W] [kW] [kW] Type
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
175U3118 270 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3119 270 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3120 200 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3121 200 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3122 200 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3123 200 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3124 145 450 5.0 1.25 1 4.0 12 16 6 - - - -
175U3125 145 450 5.0 1.25 1 4.0 12 16 6 - - - -
175U3126 145 1700 21.1 5.7 1 4.0 12 16 6 - - - -
175U3127 145 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3130 110 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3131 110 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3132 105 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3133 105 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3134 105 4200 52.5 14.8 1 4.0 12 55 1/0 - - - -
175U3135 105 4200 52.5 14.8 1 4.0 12 55 1/0 - - - -
175U3136 100 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3137 100 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3138 80 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3139 80 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3140 72 2800 35.0 8.7 1 4.0 12 16 6 - - - -
175U3141 72 2800 35.0 8.7 1 4.0 12 16 6 - - - -
175U3142 72 4200 52.5 14.8 1 4.0 12 55 1/0 - - - -
175U3143 72 4200 52.5 14.8 1 4.0 12 55 1/0 - - - -
175U3144 70 790 9.5 2.37 1 4.0 12 16 6 - - - -
175U3145 70 790 9.5 2.37 1 4.0 12 16 6 - - - -
175U3146 56 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3147 56 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3148 52 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3149 52 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3152 48 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3153 48 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3154 42 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3155 42 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3156 38 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3157 38 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3160 35 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3161 35 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3162 31 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3163 31 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3166 28 6300 78.7 19.5 1 6.0 10 55 1/0 - - - -
175U3167 28 6300 78.7 19.5 1 6.0 10 55 1/0 - - - -
175U3168 27 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3169 27 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3170 22 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3171 22 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3172 18 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3173 18 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3174 13 3500 43.4 10.8 1 4.0 12 55 1/0 - - - -
175U3175 13 3500 43.4 10.8 1 4.0 12 55 1/0 - - - -
175U3176 9.0 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3177 9.0 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3178 5.7 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3179 5.7 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3180 5.7 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3181 5.7 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3182 3.5 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3183 3.5 8200 102.2 25.3 1 6.0 10 55 1/0 - - - -
175U3200 27.0 10000
134 33
2 2.5 14 2xM8 - - - -
Specifications Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 69
