P/N
Resi-
stance
Continuous
power 100%
load
Pulse
load
power
10%
duty
cycle
1)
Pulse
load
power
40%
duty
cycle
1)
Temp.
switch
2)
3)
Terminal max wire
cross-section
Wire cross-section
4)
Temp. switch Power cables Temp. switch Power cables
[Ω]
[W] [kW] [kW] Type
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
175U3201 27.0 14000 188 46 2 2.5 14 2xM8 - - - -
175U3202 22.0 17000 228 55 2 2.5 14 2xM8 - - - -
175U3203 19.0 10000 134 33 2 2.5 14 2xM8 - - - -
175U3204 19 14000 188 46 2 2.5 14 2xM8 - - - -
175U3205 15.5 21000 282 68 2 2.5 14 2xM8 - - - -
175U3206 14.0 14000 188 46 2 2.5 14 2xM8 - - - -
175U3207 14.0 17000 228 55 2 2.5 14 2xM8 - - - -
175U3208 13.5 21000 282 68 2 2.5 14 2xM8 - - - -
175U3209 13.5 26000 349 85 2 2.5 14 2xM8 - - - -
175U3210 12.0 17000 228 55 2 2.5 14 2xM8 - - - -
175U3211 11.0 26000 349 85 2 2.5 14 2xM8 - - - -
175U3212 11.0 36000 483 117 2 2.5 14 2xM8 - - - -
175U3213 9.5 21000 282 68 2 2.5 14 2xM8 - - - -
175U3214 9.1 42000 563 137 2 2.5 14 2xM8 - - - -
175U3215 7.4 52000 697 169 2 2.5 14 2xM8 - - - -
175U3216 7.0 26000 349 85 2 2.5 14 2xM8 - - - -
175U3217 7.0 36000 483 117 2 2.5 14 2xM8 - - - -
175U3218 6.1 60000 805 195 2 2.5 14 2xM8 - - - -
175U3219 5.5 36000 483 117 2 2.5 14 2xM8 - - - -
175U3220 5.0 78000 105 254 2 2.5 14 2xM8 - - - -
175U3221 4.7 42000 563 137 2 2.5 14 2xM8 - - - -
175U3222 4.0 90000 121 293 2 2.5 14 2xM8 - - - -
175U3223 3.7 52000 69 169 2 2.5 14 2xM8 - - - -
175U3224 3.5 14000 188 46 2 2.5 14 2xM8 - - - -
175U3225 3.3 60000 805 195 2 2.5 14 2xM8 - - - -
175U3227 2.8 17000 228 55 2 2.5 14 2xM8 - - - -
175U3228 2.7 78000 105 254 2 2.5 14 2xM8 - - - -
175U3230 2.1 90000 121 293 2 2.5 14 2xM8 - - - -
175U3231 5.5 7000 94 23 2 2.5 14 2xM8 - - - -
175U3232 11 7000 94 23 2 2.5 14 2xM8 - - - -
175U3233 5.7 6000 80 20 2 2.5 14 2xM8 - - - -
175U3234 5.7 8000 107 26 2 2.5 14 2xM8 - - - -
175U3235 3.5 9000 121 29 2 2.5 14 2xM8 - - - -
175U3236 38 5000 67 16 2 2.5 14 2xM8 - - - -
175U3237 28 6000 80 20 2 2.5 14 2xM8 - - - -
175U3238 22 8000 107 26 2 2.5 14 2xM8 - - - -
175U3239 38 6000 80 20 2 2.5 14 2xM8 - - - -
175U3240 31 8000 107 26 2 2.5 14 2xM8 - - - -
175U3241 7.0 30000 402 98 2 2.5 14 2xM8 - - - -
175U3242 52 6000 80 20 2 2.5 14 2xM8 - - - -
175U3243 42 8000 107 26 2 2.5 14 2xM8 - - - -
175U3244 31 10000 134 33 2 2.5 14 2xM8 - - - -
175U3245 7 7000 94 23 2 2.5 14 2xM8 - - - -
175U3300 145 300 5 1 1 - - - - 0.5 20 1.5 16
175U3301 100 450 5 1.25 1 - - - - 0.5 20 1.5 16
175U3302 70 570 6.6 1.65 1 - - - - 0.5 20 1.5 16
175U3303 48 960 11.5 2.88 1 - - - - 0.5 20 1.5 16
175U3304 35 1130 14.5 3.6 1 - - - - 0.5 20 1.5 16
175U3305 27 1400 17.5 4.38 1 - - - - 0.5 20 6.0 10
175U3306 18 2200 27.3 6.8 1 - - - - 0.5 20 6.0 10
175U3307 13 3200 39.9 9.9 1 - - - - 0.5 20 6.0 10
175U3308 850 200 3.05 0.75 1 - - - - 0.5 20 1.5 16
175U3309 630 300 5 1 1 - - - - 0.5 20 1.5 16
175U3310 410 450 5 1.25 1 - - - - 0.5 20 1.5 16
175U3311 270 570 6.6 1.65 1 - - - - 0.5 20 1.5 16
175U3312 200 960 10.8 2.6 1 - - - - 0.5 20 1.5 16
175U3313 145 1130 14.5 3.6 1 - - - - 0.5 20 1.5 16
175U3314 110 1700 21.1 5.27 1 - - - - 0.5 20 6.0 10
175U3315 80 2200
27.3 6.8
1 - - - - 0.5 20 6.0 10
Specifications Design Guide
70 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
