P/N
Resi-
stance
Continuous
power 100%
load
Pulse
load
power
10%
duty
cycle
1)
Pulse
load
power
40%
duty
cycle
1)
Temp.
switch
2)
3)
Terminal max wire
cross-section
Wire cross-section
4)
Temp. switch Power cables Temp. switch Power cables
[Ω]
[W] [kW] [kW] Type
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
175U3316 56 3200 39.9 9.9 1 - - - - 0.5 20 6.0 10
175U3317 850 280 2.8 0.7 1 - - - - 0.5 20 1.5 16
175U3318 570 450 5 1.25 1 - - - - 0.5 20 1.5 16
175U3319 415 570 6.6 1.65 1 - - - - 0.5 20 1.5 16
175U3320 270 960 10.8 2.6 1 - - - - 0.5 20 1.5 16
175U3321 200 1130 14.5 3.6 1 - - - - 0.5 20 1.5 16
175U3322 145 1700 21.1 5.27 1 - - - - 0.5 20 6.0 14
175U3323 100 2200 27.3 6.8 1 - - - - 0.5 20 6.0 10
175U3324 72 3200 39.9 9.9 1 - - - - 0.5 20 6.0 10
175U3325 35 300 5 1 1 - - - - 0.5 20 1.5 16
175U3326 27 360 4.2 1.05 1 - - - - 0.5 20 1.5 16
175U3327 18 570 6.6 1.65 1 - - - - 0.5 20 1.5 16
175U3328 13 680 9.4 2.2 1 - - - - 0.5 20 1.5 16
175U3329 9.0 1130 14.5 3.6 1 - - - - 0.5 20 1.5 16
175U3330 5.7 1400 17.5 4.38 1 - - - - 0.5 20 6.0 10
175U3331 5.7 1700 21.1 5.27 1 - - - - 0.5 20 6.0 10
175U3332 3.5 2200 27.3 6.8 1 - - - - 0.5 20 6.0 10
175U3333 3.5 2800 35.0 8.7 1 - - - - 0.5 20 6.0 10
175U3334 2.8 3200 39.9 9.9 1 - - - - 0.5 20 6.0 10
175U3335 110 450 6.6 1.65 1 - - - - 0.5 20 1.5 16
175U3336 80 570 5.0 1.25 1 - - - - 0.5 20 1.5 16
175U3337 56 680 9.4 2.2 1 - - - - 0.5 20 1.5 16
175U3338 38 1130 14.5 3.6 1 - - - - 0.5 20 1.5 16
175U3339 28 1400 17.5 4.38 1 - - - - 0.5 20 6.0 10
175U3340 22 1700 21.1 5.27 1 - - - - 0.5 20 6.0 10
175U3341 14 2800 35 8.7 1 - - - - 0.5 20 6.0 10
175U3342 200 300 5 1 1 - - - - 0.5 20 1.5 16
175U3343 145 450 5 1.25 1 - - - - 0.5 20 1.5 16
175U3344 100 570 6.6 1.65 1 - - - - 0.5 20 1.5 16
175U3345 72 680 9.4 2.2 1 - - - - 0.5 20 1.5 16
175U3346 52 1130 14.5 3.6 1 - - - - 0.5 20 1.5 16
175U3347 38 1400 17.5 4.38 1 - - - - 0.5 20 6.0 10
175U3348 31 1700 21.1 5.27 1 - - - - 0.5 20 6.0 10
175U3349 27 2200 27.3 6 1 - - - - 0.5 20 6.0 10
175U3350 19 2800 35 8.7 1 - - - - 0.5 20 6.0 10
175U3351 72 1130 14.5 3.6 1 - - - - 0.5 20 1.5 16
175U3352 52 1400 17.5 4.38 1 - - - - 0.5 20 6.0 10
175U3353 42 1700 21.1 5.27 1 - - - - 0.5 20 6.0 10
175U3354 31 2200 27.3 6.8 1 - - - - 0.5 20 6.0 10
175U3355 27 2800 35 8.7 1 - - - - 0.5 20 6.0 10
175U3356 22 3200 39.9 9.9 1 - - - - 0.5 20 6.0 10
175U3357 19 2200 27.3 6.8 1 - - - - 0.5 20 6.0 10
175U3358 14 3200 39.9 9.9 1 - - - - 0.5 20 6.0 10
175U3359 12 3200 39.9 9.9 1 - - - - 0.5 20 6.0 10
175U3360 105 790 9.5 2.37 1 - - - - 0.5 20 1.5 16
175U3361 270 300 5 1 1 - - - - 0.5 20 1.5 16
175U3401 100 450 5 1.2 1 4.0 12 16 6 - - - -
175U3402 100 450 5 1.25 1 4.0 12 16 6 - - - -
175U3403 70 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3404 70 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3405 48 960 11.5 2.88 1 4.0 12 16 6 - - - -
175U3406 48 960 11.5 2.88 1 4.0 12 16 6 - - - -
175U3407 35 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3408 35 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3409 27 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3410 27 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3411 18 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3412 18 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3413 13 3200
39.9 9.9
1 4.0 12 16 6 - - - -
Specifications Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 71
