P/N
Resi-
stance
Continuous
power 100%
load
Pulse
load
power
10%
duty
cycle
1)
Pulse
load
power
40%
duty
cycle
1)
Temp.
switch
2)
3)
Terminal max wire
cross-section
Wire cross-section
4)
Temp. switch Power cables Temp. switch Power cables
[Ω]
[W] [kW] [kW] Type
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
[mm
2
]
[AWG]
175U3414 13 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3415 410 450 5 1.25 1 4.0 12 16 6 - - - -
175U3416 410 450 5 1.25 1 4.0 12 16 6 - - - -
175U3417 270 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3418 270 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3419 200 960 10.8 2.6 1 4.0 12 16 6 - - - -
175U3420 200 960 10.8 2.6 1 4.0 12 16 6 - - - -
175U3421 145 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3422 145 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3423 110 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3424 110 1700 21.1 5.27 1 4.0 12 16 6 - - - -
175U3427 56 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3428 56 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3429 570 450 5 1.25 1 4.0 12 16 6 - - - -
175U3430 570 450 5 1.25 1 4.0 12 16 6 - - - -
175U3431 415 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3432 415 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3433 270 960 10.8 2.6 1 4.0 12 16 6 - - - -
175U3434 270 960 10.8 2.6 1 4.0 12 16 6 - - - -
175U3435 200 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3436 200 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3437 100 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3438 100 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3439 72 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3440 72 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3441 18 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3442 18 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3445 5.7 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3446 5.7 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3447 3.5 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3448 3.5 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3449 110 450 5 1.25 1 4.0 12 16 6 - - - -
175U3450 110 450 5 1.25 1 4.0 12 16 6 - - - -
175U3451 80 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3452 80 570 6.6 1.65 1 4.0 12 16 6 - - - -
175U3455 72 680 9.4 2.2 1 4.0 12 16 6 - - - -
175U3456 72 680 9.4 2.2 1 4.0 12 16 6 - - - -
175U3457 52 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3458 52 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3459 38 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3460 38 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3461 19 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3462 19 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3463 14 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3464 14 3200 39.9 9.9 1 4.0 12 16 6 - - - -
175U3465 72 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3466 72 1130 14.5 3.6 1 4.0 12 16 6 - - - -
175U3467 52 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3468 52 1400 17.5 4.38 1 4.0 12 16 6 - - - -
175U3469 31 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3470 31 2200 27.3 6.8 1 4.0 12 16 6 - - - -
175U3471 27 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3472 27 2800 35 8.7 1 4.0 12 16 6 - - - -
175U3473 15.5 4200 52.5 14.8 1 4.0 12 55 1/0 - - - -
175U3474 15.5 4200 52.5 14.8 1 4.0 12 55 1/0 - - - -
175U3475 13.5 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3476 13.5 5500 68.6 17 1 4.0 12 55 1/0 - - - -
175U3477 27 360 4.2 1.05 1 4.0 12 16 6 - - - -
175U3478 27
360 4.2 1.05
1 4.0 12 16 6 - - - -
Specifications Design Guide
72 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
