P/N
Weight
[kg]
Enclosure
rating
[IP class]
UL Product type Drawing type Drawing reference
175U3428 14.6 21 N 914CBT-H760DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3429 2.4 65 Y 914CBR-V260BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3430 2.4 21 Y 914CBR-V260DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3431 3 65 Y 914CBR-V330BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3432 3 21 Y 914CBR-V330DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3433 4.6 65 Y 914CBR-V560BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3434 4.6 21 Y 914CBR-V560DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3435 5.4 65 Y 914CBR-V660BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3436 5.4 21 Y 914CBR-V660DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3437 11 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3438 11 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3439 14.6 65 N 914CBT-H760BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3440 14.6 21 N 914CBT-H760DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3441 3 65 Y 914CBR-V330BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3442 3 21 Y 914CBR-V330DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3445 8.2 65 N 914CBT-H400BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3446 8.2 21 N 914CBT-H400DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3447 12.8 65 N 914CBT-H660BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3448 12.8 21 N 914CBT-H660DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3449 2.4 65 Y 914CBR-V260BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3450 2.4 21 Y 914CBR-V260DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3451 3 65 Y 914CBR-V330BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3452 3 21 Y 914CBR-V330DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3455 3.5 65 Y 914CBR-V400BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3456 3.9 21 Y 914CBR-V400DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3457 5.4 65 Y 914CBR-V660BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3458 5.4 21 Y 914CBR-V660DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3459 8.2 65 N 914CBT-H400BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3460 8.2 21 N 914CBT-H400DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3461 12.8 65 N 914CBT-H660BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3462 12.6 21 N 914CBT-H660DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3463 14.6 65 N 914CBT-H760BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3464 14.6 21 N 914CBT-H760DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3465 5.4 65 Y 914CBR-V660BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3466 5.4 21 Y 914CBR-V660DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3467 8.2 65 N 914CBT-H400BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3468 8.2 21 N 914CBT-H400DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3469 11 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3470 11 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3471 12.8 65 N 914CBT-H660BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3472 12.8 21 N 914CBT-H660DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3473 30 65 N 929CBT-V660BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3474 29 21 N 929CBT-V660GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3475 33.5 65 N 929CBT-V760BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3476 32.5 21 N 929CBT-V760GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3477 1.8 21 Y 914CBR-V210DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3478 1.8 65 Y 914CBR-V210BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3479 14.6 21 N 914CBT-H760DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3480 14.6 65 N 914CBT-H760BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3481 3.9 21 Y 914CBR-V460DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3482 3.9 65 Y 914CBR-V460BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
Specifications Design Guide
80 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
