P/N
Weight
[kg]
Enclosure
rating
[IP class]
UL Product type Drawing type Drawing reference
175U3336 3 54 Y 914CBR-V330CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3337 3.5 54 Y 914CBR-V400CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3338 5.4 54 Y 914CBR-V660CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3339 8.2 54 Y 914CBT-H400CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3340 9.2 54 Y 914CBT-H460CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3341 12.8 54 Y 914CBT-H660CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3342 1.58 54 Y 914CCH355CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3343 2.4 54 Y 914CBR-V260CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3344 3 54 Y 914CBR-V330CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3345 3.5 54 Y 914CBR-V400CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3346 5.4 54 Y 914CBR-V660CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3347 8.2 54 Y 914CBT-H400CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3348 9.2 54 Y 914CBT-H460CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3349 11 54 Y 914CBT-H560CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3350 12.8 54 Y 914CBT-H660CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3351 5.4 54 Y 914CBR-V660CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3352 8.2 54 Y 914CBT-H400CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3353 9.2 54 Y 914CBT-H460CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3354 11 54 Y 914CBT-H560CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3355 12.8 54 Y 914CBT-H660CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3356 14.6 54 Y 914CBT-H760CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3357 11 54 Y 914CBT-H560CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3358 14.6 54 Y 914CBT-H760CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3359 14.6 54 Y 914CBT-H760CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3360 3.9 54 Y 914CBR-V460CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3361 1.58 54 Y 914CCH355CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3401 2.4 65 Y 914CBR-V260BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3402 2.4 21 Y 914CBR-V260DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3403 3 65 Y 914CBR-V330BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3404 3 21 Y 914CBR-V330DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3405 4.6 65 Y 914CBR-V560BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3406 4.6 21 Y 914CBR-V560DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3407 5.4 65 Y 914CBR-V660BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3408 5.4 21 Y 914CBR-V660DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3409 8.2 65 N 914CBT-H400BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3410 8.2 21 N 914CBT-H400DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3411 11 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3412 11 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3413 14.6 65 N 914CBT-H760BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3414 14.6 21 N 914CBT-H760DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3415 2.4 65 Y 914CBR-V260BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3416 2.4 21 Y 914CBR-V260DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3417 3 65 Y 914CBR-V330BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3418 3 21 Y 914CBR-V330DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3419 4.6 65 Y 914CBR-V560BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3420 4.6 21 Y 914CBR-V560DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3421 5.4 65 Y 914CBR-V660BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3422 5.4 21 Y 914CBR-V660DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3423 9.2 65 N 914CBT-H460BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3424 9.2 21 N 914CBT-H460DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3427 14.6 65 N 914CBT-H760BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
Specifications Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 79
