Danfoss VLT Brake Resistor MCE 101 User Manual

P/N
Weight
[kg]
Enclosure
rating
[IP class]
UL Product type Drawing type Drawing reference
175U3231 19 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3232 19 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3233 19 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3234 20 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3235 21 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3236 15 20 N 917CM13 917CM13 chapter 9.7.8 Figure 8 - 917CM13
175U3237 19 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3238 20 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3239 19 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3240 20 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3241 52 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3242 19 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3243 20 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3244 22 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3245 20 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3300 1.58 54 Y 914CCH355CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3301 2.4 54 Y 914CBR-V260CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3302 3 54 Y 914CBR-V330CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3303 4.6 54 Y 914CBR-V560CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3304 5.4 54 Y 914CBR-V660CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3305 8.2 54 Y 914CBT-H400CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3306 11 54 Y 914CBT-H560CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3307 14.6 54 Y 914CBT-H760CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3308 0.54 54 Y 914CCH251CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3309 1.58 54 Y 914CCH355CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3310 2.4 54 Y 914CBR-V260CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3311 3 54 Y 914CBR-V330CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3312 4.6 54 Y 914CBR-V560CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3313 5.4 54 Y 914CBR-V660CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3314 9.2 54 Y 914CBT-H460CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3315 11 54 Y 914CBT-H560CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3316 14.6 54 Y 914CBT-H760CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3317 1.3 54 Y 914CBR-V160CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3318 2.4 54 Y 914CBR-V260CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3319 3 54 Y 914CBR-V330CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3320 4.6 54 Y 914CBR-V560CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3321 5.4 54 Y 914CBR-V660CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3322 9.2 54 N 914CBT-H460CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3323 11 54 Y 914CBT-H560CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3324 14.6 54 Y 914CBT-H760CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3325 1.58 54 Y 914CCH355CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3326 1.8 54 Y 914CBR-V210CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3327 3 54 Y 914CBR-V330CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3328 3.5 54 Y 914CBR-V400CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3329 5.4 54 Y 914CBR-V660CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
175U3330 8.2 54 Y 914CBT-H400CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3331 9.2 54 Y 914CBT-H460CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3332 11 54 Y 914CBT-H560CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3333 12.8 54 Y 914CBT-H660CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3334 14.6 54 Y 914CBT-H760CHT 914CBT-HxxxCHT chapter 9.7.2 Figure 2 - 914CBT-HxxxCHT
175U3335 2.4 54 Y 914CBR-V260CT 914CBR-VxxxCT chapter 9.7.5 Figure 5 - 914CBR-VxxxCT
Specifications Design Guide
78 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
