Danfoss VLT Brake Resistor MCE 101 User Manual

P/N
Weight
[kg]
Enclosure
rating
[IP class]
UL Product type Drawing type Drawing reference
175U3160 9.2 21 N 914CBT-H460DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3161 9.2 65 N 914CBT-H460BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3162 44.5 21 N 930CBT-V760GHT 930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
175U3163 44.5 65 N 930CBT-V760BGHT 930CBT-VxxxBGHT chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
175U3166 39 21 N 930CBT-V660GHT 930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
175U3167 39 65 N 930CBT-V660BGHT 930CBT-VxxxBGHT chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
175U3168 11.0 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3169 11.0 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3170 44.5 21 N 930CBT-V760GHT 930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
175U3171 44.5 65 N 930CBT-V760BGHT 930CBT-VxxxBGHT chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
175U3172 14.6 21 N 914CBT-H760DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3173 14.6 65 N 914CBT-H760BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3174 25.5 21 N 929CBT-V560GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3175 26.5 65 N 929CBT-V560BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3176 32.5 21 N 929CBT-V760GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3177 33.5 65 N 929CBT-V760BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3178 32.5 21 N 929CBT-V760GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3179 33.5 65 N 929CBT-V760BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3180 44.5 21 N 930CBT-V760GHT 930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
175U3181 44.5 65 N 930CBT-V760BGHT 930CBT-VxxxBGHT chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
175U3182 44.5 21 N 930CBT-V760GHT 930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
175U3183 44.5 65 N 930CBT-V760BGHT 930CBT-VxxxBGHT chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
175U3200 22 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3201 25 20 N 917CM17 917CM17 chapter 9.7.10 Figure 10 - 917CM17
175U3202 35 20 N 917CM25 917CM25 chapter 9.7.11 Figure 11 - 917CM25
175U3203 20 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3204 25 20 N 917CM17 917CM17 chapter 9.7.10 Figure 10 - 917CM17
175U3205 41 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3206 25 20 N 917CM17 917CM17 chapter 9.7.10 Figure 10 - 917CM17
175U3207 35 20 N 917CM25 917CM25 chapter 9.7.11 Figure 11 - 917CM25
175U3208 41 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3209 45 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3210 35 20 N 917CM25 917CM25 chapter 9.7.11 Figure 11 - 917CM25
175U3211 45 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3212 74 20 N 917CM37 917CM37 chapter 9.7.13 Figure 13 - 917CM37
175U3213 41 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3214 78 20 N 917CM37 917CM37 chapter 9.7.13 Figure 13 - 917CM37
175U3215 90 20 N 917CMD27 917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
175U3216 45 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3217 74 20 N 917CM37 917CM37 chapter 9.7.13 Figure 13 - 917CM37
175U3218 90 20 N 917CMD27 917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
175U3219 74 20 N 917CM37 917CM37 chapter 9.7.13 Figure 13 - 917CM37
175U3220 182 20 N 917CMD37 917CMD37 chapter 9.7.15 Figure 15 - 917CMD37
175U3221 78 20 N 917CM37 917CM37 chapter 9.7.13 Figure 13 - 917CM37
175U3222 190 20 N 917CMD37 917CMD37 chapter 9.7.15 Figure 15 - 917CMD37
175U3223 90 20 N 917CMD27 917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
175U3224 25 20 N 917CM17 917CM17 chapter 9.7.10 Figure 10 - 917CM17
175U3225 90 20 N 917CMD27 917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
175U3227 35 20 N 917CM25 917CM25 chapter 9.7.11 Figure 11 - 917CM25
175U3228 182 20 N 917CMD37 917CMD37 chapter 9.7.15 Figure 15 - 917CMD37
175U3230 190 20 N 917CMD37 917CMD37 chapter 9.7.15 Figure 15 - 917CMD37
Specifications Design Guide
MG90O202 Danfoss A/S © Rev. 05/2014 All rights reserved. 77
