Danfoss VLT Brake Resistor MCE 101 User Manual

P/N
Weight
[kg]
Enclosure
rating
[IP class]
UL Product type Drawing type Drawing reference
175U3103 1.8 65 Y 914CBR-V210BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3104 1.3 21 Y 914CBR-V160DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3105 1.3 65 Y 914CBR-V160BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3106 11 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3107 11 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3108 1.8 21 Y 914CBR-V210DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3109 1.8 65 Y 914CBR-V210BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3110 3 21 Y 914CBR-V330DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3111 3 65 Y 914CBR-V330BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3112 3.9 21 Y 914CBR-V460DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3113 3.9 65 Y 914CBR-V460BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3114 3 21 Y 914CBR-V330DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3115 3 65 Y 914CBR-V330BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3116 3.9 21 Y 914CBR-V460DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3117 3.9 65 Y 914CBR-V460BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3118 5.4 21 Y 914CBR-V660DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3119 5.4 65 Y 914CBR-V660BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3120 5.4 21 Y 914CBR-V660DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3121 5.4 65 Y 914CBR-V660BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3122 9.2 21 N 914CBT-H460DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3123 9.2 65 N 914CBT-H460BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3124 2.4 21 Y 914CBR-V260DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3125 2.4 65 Y 914CBR-V260BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3126 9.2 21 N 914CBT-H460DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3127 9.2 65 N 914CBT-H460BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3130 11 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3131 11 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3132 14.6 21 N 914CBT-H760DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3133 14.6 65 N 914CBT-H760BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3134 29 21 N 929CBT-V660GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3135 30 65 N 929CBT-V660BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3136 3.0 21 Y 914CBR-V330DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3137 3 65 Y 914CBR-V330BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3138 11 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3139 11 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3140 12.8 21 N 914CBT-H660DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3141 12.8 65 N 914CBT-H660BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3142 29 21 N 929CBT-V660GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3143 30 65 N 929CBT-V660BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3144 3.9 21 Y 914CBR-V460DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3145 3.9 65 Y 914CBR-V460BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3146 12.8 21 N 914CBT-H660DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3147 12.8 65 N 914CBT-H660BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3148 32.5 21 N 929CBT-V760GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3149 33.5 65 N 929CBT-V760BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3152 8.2 21 N 914CBT-H400DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3153 8.2 65 N 914CBT-H400BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3154 44.5 21 N 930CBT-V760GHT 930CBT-VxxxGHT chapter 9.7.18 Figure 18 - 930CBT-VxxxGHT
175U3155 44.5 65 N 930CBT-V760BGHT 930CBT-VxxxBGHT chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
175U3156 32.5 21 N 929CBT-V760GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3157 33.5 65 N 929CBT-V760BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
Specifications Design Guide
76 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
