Danfoss VLT Brake Resistor MCE 101 User Manual

P/N
Weight
[kg]
Enclosure
rating
[IP class]
UL Product type Drawing type Drawing reference
175U3051 25.5 21 N 929CBT-V560GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3052 26.5 65 N 929CBT-V560BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3053 2.4 21 Y 914CBR-V260DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3054 1.3 65 Y 914CBR-V260BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3055 12.8 21 N 914CBT-H660DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3056 12.8 65 N 914CBT-H660BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3057 29 21 N 929CBT-V660GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3058 30 65 N 929CBT-V660BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3059 3.5 21 Y 914CBR-V400DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3060 3.5 65 Y 914CBR-V400BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3061 14.6 21 N 914CBT-H760DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3062 14.6 65 N 914CBT-H760BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3063 32.5 21 N 929CBT-V760GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3064 33.5 65 N 929CBT-V760BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3065 29 21 N 929CBT-V660GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3066 30 65 N 929CBT-V660BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3067 21 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3068 5.4 21 Y 914CBR-V660DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
175U3069 5.4 65 Y 914CBR-V660BT 914CBR-VxxxBT chapter 9.7.6 Figure 6 - 914CBR-VxxxBT
175U3070 32.5 21 N 929CBT-V760GHT 929CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3071 33.5 65 N 929CBT-V760BGHT 929CBT-VxxxBGHT chapter 9.7.17 Figure 17 - 929CBT-VxxxBGHT
175U3072 24 20 N 917CM17 917CM17 chapter 9.7.10 Figure 10 - 917CM17
175U3073 8.2 21 N 914CBT-H400DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3074 8.2 65 N 914CBT-H400BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3075 25 20 N 917CM17 917CM17 chapter 9.7.10 Figure 10 - 917CM17
175U3076 39 21 N 930CBT-V660GHT 930CBT-VxxxGHT chapter 9.7.16 Figure 16 - 929CBT-VxxxGHT
175U3077 39 65 N 930CBT-V660BGHT 930CBT-VxxxBGHT chapter 9.7.19 Figure 19 - 930CBT- VxxxBGHT
175U3078 35 20 N 917CM25 917CM25 chapter 9.7.11 Figure 11 - 917CM25
175U3079 21 20 N 917CM15 917CM15 chapter 9.7.9 Figure 9 - 917CM15
175U3080 11 21 N 914CBT-H560DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3081 11 65 N 914CBT-H560BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3082 37 20 N 917CM25 917CM25 chapter 9.7.11 Figure 11 - 917CM25
175U3083 24 20 N 917CM17 917CM17 chapter 9.7.10 Figure 10 - 917CM17
175U3084 25 20 N 917CM17 917CM17 chapter 9.7.10 Figure 10 - 917CM17
175U3085 45 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3086 14.6 21 N 914CBT-H760DHT 914CBT-HxxxDHT chapter 9.7.1 Figure 1 - 914CBT-HxxxDHT
175U3087 14.6 65 N 914CBT-H760BHT 914CBT-HxxxBHT chapter 9.7.3 Figure 3 - 914CBT-HxxxBHT
175U3088 35 20 N 917CM25 917CM25 chapter 9.7.11 Figure 11 - 917CM25
175U3089 48 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3090 74 20 N 917CM37 917CM37 chapter 9.7.13 Figure 13 - 917CM37
175U3091 37 20 N 917CM25 917CM25 chapter 9.7.11 Figure 11 - 917CM25
175U3092 78 20 N 917CM37 917CM37 chapter 9.7.13 Figure 13 - 917CM37
175U3093 45 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3094 90 20 N 917CMD27 917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
175U3095 90 20 N 917CMD27 917CMD27 chapter 9.7.14 Figure 14 - 917CMD27
175U3096 0.54 54 Y 914CCH251CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3097 48 20 N 917CM27 917CM27 chapter 9.7.12 Figure 12 - 917CM27
175U3098 74 20 N 917CM37 917CM37 chapter 9.7.13 Figure 13 - 917CM37
175U3099 78 20 N 917CM37 917CM37 chapter 9.7.13 Figure 13 - 917CM37
175U3101 0.54 54 Y 914CCH251CT 914CCHxxxCT chapter 9.7.7 Figure 7 - 914CCHxxxCT
175U3102 1.8 21 Y 914CBR-V210DT 914CBR-VxxxDT chapter 9.7.4 Figure 4 - 914CBR-VxxxDT
Specifications Design Guide
