Danfoss VLT CANopen MCA 105 Programming Guide

Option
Name
Description
[45]
Analog input X49/5
[50]
FALSE
Use to enter the fixed value False in the comparator.
[51]
TRUE
Use to enter True in the comparator.
[52]
Control ready
The control board receives supply voltage.
[53]
Drive ready
The drive is ready for operation and applies a signal on the control board.
[54]
Running
The motor runs.
[55]
Reversing
The output is active when the drive runs counterclockwise (the logical product of the status
bits running AND reverse).
[56]
In range
The motor runs within the programmed current and speed ranges set in parameter 4-50 Warn-
ing Current Low to parameter 4-53 Warning Speed High.
[60]
On reference
The motor runs on reference.
[61]
Below reference, low
The motor runs at a reference which is less than the value in parameter 4-54 Warning Reference
Low.
[62]
Above ref, high
The motor runs at a reference which exceeds the value in parameter 4-55 Warning Reference
High.
[65]
Torque limit
The torque exceeds the value in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Tor-
que Limit Generator Mode.
[66]
Current limit
The motor current exceeds the value in parameter 4-18 Current Limit.
[67]
Out of current range
The motor current is outside the range set in parameter 4-18 Current Limit.
[68]
Below I low
The motor current is lower than the value in parameter 4-50 Warning Current Low.
[69]
Above I high
The motor current is higher than the value in parameter 4-51 Warning Current High.
[70]
Out of speed range
The speed is outside the range set in parameter 4-52 Warning Speed Low and parameter 4-53
Warning Speed High.
[71]
Below speed low
The output speed is lower than the value in parameter 4-52 Warning Speed Low.
[72]
Above speed high
The output speed is higher than the value in parameter 4-53 Warning Speed High.
[75]
Out of feedack range
The feedback is outside the range set in parameter 4-56 Warning Feedback Low and parameter
4-57 Warning Feedback High.
[76]
Below feedback low
The feedback is lower than the limit set in parameter 4-56 Warning Feedback Low.
[77]
Above feedback high
The feedback exceeds the limit set in parameter 4-57 Warning Feedback High.
[80]
Thermal warning
This operand becomes true when the drive detects any thermal warning, for instance when the
temperature exceeds the limit in the motor, the drive, the brake resistor, or thermistor.
[82]
Mains out of range
The mains voltage is outside the specified voltage range.
[85]
Warning
If a warning is triggered, this operand gets the warning number.
[86]
Alarm (trip)
A trip alarm is active.
[87]
Alarm (trip lock)
A trip lock alarm is active.
[90]
Bus OK
Active communication (no timeout) via the serial communication port.
AU275636650261en-000101 / 130R0334 | 383Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
