Danfoss VLT CDS 803 Programming Guide

5.1.4 2-** Brakes
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conversion
index
Type
2-0* DC-Brake
2-00 DC Hold/Motor Preheat Current 0% All set-ups FALSE 0 Uint16
2-01 DC Brake Current Expression Limit All set-ups FALSE 0 Uint16
2-02 DC Braking Time 0.8 s All set-ups FALSE -1 Uint16
2-04 DC Brake Cut In Speed 0.1 Hz All set-ups FALSE -1 Uint16
2-06 Parking Current 60% All set-ups FALSE 0 Uint16
2-07 Parking Time 2 s All set-ups FALSE -1 Uint16
2-1* Brake Energy Funct.
2-17 Over-voltage Control [2] Enabled All set-ups FALSE – Uint8
5.1.5 3-** Reference/Ramps
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
3-0* Reference Limits
3-02 Minimum Reference 30 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
3-03 Maximum Reference 200 ReferenceFeedbackUnit All set-ups TRUE -3 Int32
3-1* References
3-10 Preset Reference 0 % All set-ups TRUE -2 Int16
3-11 Jog Speed [Hz] 30 Hz All set-ups TRUE -1 Uint16
3-14 Preset Relative Reference 0 % All set-ups TRUE -2 Int16
3-15 Reference 1 Source [1] Analog Input 53 All set-ups TRUE - Uint8
3-16 Reference 2 Source [2] Analog Input 54 All set-ups TRUE - Uint8
3-17 Reference 3 Source [11] Local bus reference All set-ups TRUE - Uint8
3-4* Ramp 1
3-41 Ramp 1 Ramp Up Time 90 s All set-ups TRUE -2 Uint32
3-42 Ramp 1 Ramp Down Time 30 s All set-ups TRUE -2 Uint32
3-5* Ramp 2
3-51 Ramp 2 Ramp Up Time 30 s All set-ups TRUE -2 Uint32
3-52 Ramp 2 Ramp Down Time 30 s All set-ups TRUE -2 Uint32
3-8* Other Ramps
3-80 Jog Ramp Time ExpressionLimit All set-ups TRUE -2 Uint32
3-81 Quick Stop Ramp Time 10.00 s 1 set-up TRUE -2 Uint32
3-82 Starting Ramp Up Time 15.00 s 2 set-ups TRUE -2 Uint32
3-83 Stopping Ramp Down Time 15.00 s All set-ups TRUE -2 Uint32
5.1.6 4-** Limits/Warnings
Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
4-1* Motor Limits
4-10 Motor Speed Direction [0] Clockwise All set-ups FALSE - Uint8
4-12 Motor Speed Low Limit [Hz] ExpressionLimit All set-ups FALSE -1 Uint16
4-14 Motor Speed High Limit [Hz] 200 Hz All set-ups FALSE -1 Uint16
4-18 Current Limit ExpressionLimit All set-ups TRUE 0 Uint16
4-19 Max Output Frequency 200 Hz All set-ups FALSE -1 Uint16
Parameter Lists
VLT
®
Compressor Drive CDS 803
78 Danfoss A/S © 06/2019 All rights reserved. MG18P202
55
