Danfoss VLT CDS 803 Programming Guide

Par.
No. #
Parameter description Default value 2-set-up Change
during
operation
Conver-
sion index
Type
16-12 Motor Voltage 0 V 1 set-up TRUE -1 Uint32
16-13 Frequency 0 Hz 1 set-up TRUE -1 Uint32
16-14 Motor current 0 A 1 set-up TRUE -2 Uint16
16-15 Frequency [%] 0 % 1 set-up TRUE -1 Uint16
16-16 Torque [Nm] 0 Nm All set-ups FALSE -1 Int32
16-18 Motor Thermal 0 % 1 set-up TRUE 0 Uint8
16-22 Torque [%] 0 % All set-ups FALSE 0 Int16
16-3* Drive Status
16-30 DC Link Voltage 0 V 1 set-up TRUE 0 Uint32
16-34 Heatsink Temp. 0 °C 1 set-up TRUE 100 Int8
16-35 Inverter Thermal 0 % 1 set-up TRUE 0 Uint8
16-36 Inv. Nom. Current 0 A 1 set-up TRUE -2 Uint16
16-37 Inv. Max. Current 0 A 1 set-up TRUE -2 Uint16
16-38 SL Controller State 0 N/A 1 set-up TRUE 0 Uint8
16-5* Ref. & Feedb.
16-50 External Reference 0 % 1 set-up TRUE -1 Int16
16-52 Feedback[Unit] 0 ProcessCtrlUnit 1 set-up TRUE -3 Int32
16-54 Feedback 1 [Unit] 0 ProcessCtrlUnit All set-ups TRUE -3 Int32
16-55 Feedback 2 [Unit] 0 ProcessCtrlUnit All set-ups FALSE -3 Int32
16-6* Inputs & Outputs
16-60 Digital Input 0 N/A 1 set-up TRUE 0 Uint16
16-61 Terminal 53 Setting [0] Current mode 1 set-up TRUE - Uint8
16-62 Analog Input AI53 1 N/A 1 set-up TRUE -2 Uint16
16-63 Terminal 54 Setting [0] Current mode 1 set-up TRUE - Uint8
16-64 Analog Input AI54 1 N/A 1 set-up TRUE -2 Uint16
16-65 Analog Output AO42 [mA] 0 mA 1 set-up TRUE -2 Uint16
16-66 Digital Output 0 N/A 1 set-up TRUE 0 VisStr[4]
16-67 Pulse Input #29 [Hz] 0 N/A All set-ups FALSE 0 Int32
16-71 Relay Output [bin] 0 N/A 1 set-up TRUE 0 Uint16
16-72 Counter A 0 N/A 1 set-up TRUE 0 Int16
16-73 Counter B 0 N/A 1 set-up TRUE 0 Int16
16-79 Analog Output AO45 0 mA 1 set-up TRUE -2 Uint16
16-8* Fieldbus & FC Port
16-86 FC Port REF 1 0 N/A 1 set-up TRUE 0 Int16
16-9* Diagnosis Readouts
16-90 Alarm Word 0 N/A 1 set-up TRUE 0 Uint32
16-91 Alarm Word 2 0 N/A 1 set-up TRUE 0 Uint32
16-92 Warning Word 0 N/A 1 set-up TRUE 0 Uint32
16-93 Warning Word 2 0 N/A 1 set-up TRUE 0 Uint32
16-94 Ext. Status Word 0 N/A 1 set-up TRUE 0 Uint32
16-95 Ext. Status Word 2 0 N/A 1 set-up TRUE 0 Uint32
16-97 Alarm Word 3 0 N/A 1 set-up TRUE 0 Uint32
Parameter Lists
VLT
®
Compressor Drive CDS 803
84 Danfoss A/S © 06/2019 All rights reserved. MG18P202
