Illustration 3: Possible Congurations for an E5h or E6h Enclosed Drive
1
Input lter cabinet (passive harmonic lter or line re-
actor)
2
Input power options cabinet
3
Drive cabinet
4
Sine-wave lter cabinet
5
Control compartment
6
dU/dt lter cabinet
