Figure 6.4 Adjustable Frequency Drive Power Terminals
1
Main 3-phase AC power to adjustable frequency drive 3 3-phase output to motor
2 Brake Resistor Connection (optional)
Table 6.3 Legend to Figure 6.4
Whenever possible, perform these procedures with a split bus power supply. For more information, see chapter 8.1.1 Split
Bus Power Supply.
NOTICE!
Always perform static tests (chapter 6.3 Static Test Procedures) before applying power to the unit.
Test Procedures Service Manual
78 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG94A222
66
