Fuse Tables
Size/
Type
Buss-
mann
E1958
JFHR2*
*
Buss-
mann
E4273
T/
JDDZ**
SIBA
E180276
RKI/JDDZ
LittelFuse
E71611
JFHR2**
Ferraz-
Shawmut
E60314
JFHR2**
Buss-
mann
E4274
H/
JDDZ**
Bussmann
E125085
JFHR2*
Internal
Option
Bussmann
P90K FWH-
300
JJS-
300
2028220-
315
L50S-300 A50-P300 NOS-
300
170M3017 170M3018
P110 FWH-
350
JJS-
350
2028220-
315
L50S-350 A50-P350 NOS-
350
170M3018 170M3018
P132 FWH-
400
JJS-
400
206xx32-
400
L50S-400 A50-P400 NOS-
400
170M4012 170M4016
P160 FWH-
500
JJS-
500
206xx32-
500
L50S-500 A50-P500 NOS-
500
170M4014 170M4016
P200 FWH-
600
JJS-
600
206xx32-
600
L50S-600 A50-P600 NOS-
600
170M4016 170M4016
3.5: D enclosures, 380-500 V
*170M fuses from Bussmann shown use the -/80 visual indicator; -TN/80 Type T, -/110 or TN/
110 Type T indicator fuses of the same size and amperage may be substituted for external use
**Any minimum 500 V UL listed fuse with associated current rating may be used to meet UL
requirements.
Size/Type
Bussmann
E125085
JFHR2
Amps
SIBA
E180276
JFHR2
Ferraz-Shawmut
E76491
JFHR2
P110 170M3017 315 2061032.315 6.6URD30D08A0315
P132 170M3018 350 2061032.35 6.6URD30D08A0350
P160 170M4011 350 2061032.35 6.6URD30D08A0350
P200 170M4012 400 2061032.4 6.6URD30D08A0400
P250 170M4014 500 2061032.5 6.6URD30D08A0500
P315 170M5011 550 2062032.55 6.6URD32D08A550
3.6: D enclosures, 525-690 V
Size/Type
Bussmann PN* Danfoss PN Rating Losses (W)
P250 170M4017 20220 700 A, 700 V 85
P315 170M6013 20221 900 A, 700 V 120
P355 170M6013 20221 900 A, 700 V 120
P400 170M6013 20221 900 A, 700 V 120
3.7: E enclosures, 380-500 V
*170M fuses from Bussmann shown use the -/80 visual indicator; -TN/80 Type T, -/110 or TN/
110 Type T indicator fuses of the same size and amperage may be substituted for external use.
Danfoss PN Bussmann Ferraz Siba
20220 170M4017 6.9URD31D08A0700 20 610 32.700
20221 170M6013 6.9URD33D08A0900 20 630 32.900
3.8: Additional Fuses for Non-UL Applications, E enclosures, 380-500 V
VLT
®
Automation Drive FC 300
Instruction Manual High Power
3. How to Install
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark.
61
3
