1-25 Motor Nominal Speed
Range: Function:
Size re-
lated
*
[100 - 60,000 rpm] Enter the nominal motor speed value from the motor nameplate
data. This data is used for calculating automatic motor com-
pensations.
This parameter cannot be adjusted while the motor is running.
5-12 Terminal 27 Digital Input
Option: Function:
Select the function from the available digital input range.
No operation [0]
Reset [1]
Coast inverse [2]
Coast and reset inverse [3]
Quick stop inverse [4]
DC brake inverse [5]
Stop inverse [6]
Start [8]
Latched start [9]
Reversing [10]
Start reverse [11]
Enable start forward [12]
Enable start reverse [13]
Jog [14]
Preset ref bit 0 [16]
Preset ref bit 1 [17]
Preset ref bit 2 [18]
Freeze reference [19]
Freeze output [20]
Speed up [21]
Slow [22]
Set-up select bit 0 [23]
Set-up select bit 1 [24]
Catch up [28]
Slow-down [29]
Pulse input [32]
Ramp bit 0 [34]
Ramp bit 1 [35]
Line failure inverse [36]
DigiPot Increase [55]
DigiPot Decrease [56]
DigiPot Clear [57]
Reset Counter A [62]
Reset Counter B [65]
4. How to Program
VLT
®
Automation Drive FC 300
Instruction Manual High Power
80
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark.
4
