13-51 SL Controller Event
Array [20]
Option: Function:
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[76] Digital Input x30 2
[77] Digital Input x30 3
[78] Digital Input x30 4
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
[90] ECB Drive Mode
[91] ECB Bypass Mode
[92] ECB Test Mode
[100] Fire Mode
See 13-15 RS-FF Operand S, 13-16 RS-
FF Operand R.
13-52 SL Controller Action
Array [20]
Option: Function:
Select the action corresponding to the
SLC event. Actions are executed when
the corresponding event (dened in
parameter 13-51 SL Controller Event) is
evaluated as true. The following actions
are available for selection:
[0] Disabled
[1] No action
[2] Select set-up 1 Changes the active set-up
(parameter 0-10 Active Set-up) to 1.
[3] Select set-up 2 Changes the active set-up
(parameter 0-10 Active Set-up) to 2.
[4] Select set-up 3 Changes the active set-up
(parameter 0-10 Active Set-up) to 3.
[5] Select set-up 4 Changes the active set-up
(parameter 0-10 Active Set-up) to 4. If the
set-up is changed, it merges with other
13-52 SL Controller Action
Array [20]
Option: Function:
set-up commands coming from either
the digital inputs or via a eldbus.
[10] Select preset ref
0
Selects preset reference 0.
[11] Select preset ref
1
Selects preset reference 1.
[12] Select preset ref
2
Selects preset reference 2.
[13] Select preset ref
3
Selects preset reference 3.
[14] Select preset ref
4
Selects preset reference 4.
[15] Select preset ref
5
Selects preset reference 5.
[16] Select preset ref
6
Selects preset reference 6.
[17] Select preset ref
7
Selects preset reference 7. If the active
preset reference is changed, it merges
with other preset reference commands
coming from either the digital inputs or
via a eldbus.
[18] Select ramp 1 Selects ramp 1.
[19] Select ramp 2 Selects ramp 2.
[22] Run Issues a start command to the frequency
converter.
[23] Run reverse Issues a start reverse command to the
frequency converter.
[24] Stop Issues a stop command to the frequency
converter.
[26] DC Brake Issues a DC stop command to the
frequency converter.
[27] Coast The frequency converter coasts
immediately. All stop commands
including the coast command stop the
SLC.
[28] Freeze output Freezes the output frequency of the
frequency converter.
[29] Start timer 0
Starts timer 0, see parameter 13-20 SL
Controller Timer for further description.
[30] Start timer 1
Starts timer 1, see parameter 13-20 SL
Controller Timer for further description.
[31] Start timer 2
Starts timer 2, see parameter 13-20 SL
Controller Timer for further description.
[32] Set digital out
A low
Any output with digital output 1 selected
is low (o).
[33] Set digital out B
low
Any output with digital output 2 selected
is low (o).
