13-52 SL Controller Action
Array [20]
Option: Function:
[34] Set digital out C
low
Any output with digital output 3 selected
is low (o).
[35] Set digital out
D low
Any output with digital output 4 selected
is low (o).
[36] Set digital out E
low
Any output with digital output 5 selected
is low (o).
[37] Set digital out F
low
Any output with digital output 6 selected
is low (o).
[38] Set digital out
A high
Any output with digital output 1 selected
is high (closed).
[39] Set digital out B
high
Any output with digital output 2 selected
is high (closed).
[40] Set digital out C
high
Any output with digital output 3 selected
is high (closed).
[41] Set digital out
D high
Any output with digital output 4 selected
is high (closed).
[42] Set digital out E
high
Any output with digital output 5 selected
is high (closed).
[43] Set digital out F
high
Any output with digital output 6 selected
is high (closed).
[60] Reset Counter A Resets counter A to zero.
[61] Reset Counter B Resets counter B to zero.
[62] Counter A (up)
[63] Counter A
(down)
[64] Counter B (up)
[65] Counter B
(down)
[70] Start Timer 3
Starts timer 3, see parameter 13-20 SL
Controller Timer for further description.
[71] Start Timer 4
Starts timer 4, see parameter 13-20 SL
Controller Timer for further description.
[72] Start Timer 5
Starts timer 5, see parameter 13-20 SL
Controller Timer for further description.
[73] Start Timer 6
Starts timer 6, see parameter 13-20 SL
Controller Timer for further description.
[74] Start Timer 7
Starts timer 7, see parameter 13-20 SL
Controller Timer for further description.
[80] Sleep Mode Starts the sleep mode.
[90] Set ECB Bypass
Mode
[91] Set ECB Drive
Mode
[100] Reset Alarms
