23-01 ON Action
Arra [10]
Option: Function:
[33] Set digital out B low
[34] Set digital out C low
[35] Set digital out D low
[36] Set digital out E low
[37] Set digital out F low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[62] Counter A (up)
[63] Counter A (down)
[64] Counter B (up)
[65] Counter B (down)
[80] Sleep Mode
[90] Set ECB Bypass Mode
[91] Set ECB Drive Mode
[100] Reset Alarms
23-02 OFF Time
Array [10]
Range: Function:
Size
related*
[ 0 - 0 ] Sets the OFF time for the timed action.
NOTICE
The frequency converter has no
back-up of the clock function and
the set date/time is reset to default
(2000-01-01 00:00) after a power-
down unless a real time clock
module, with back-up is installed. In
parameter 0-79 Clock Fault, it is
possible to programme a warning if
the clock has not been set properly,
for example after a power-down.
23-03 OFF Action
Array [10]
Option: Function:
Select the action during OFF time.
See parameter 13-52 SL Controller
Action for descriptions of the
options.
[1] * No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
23-03 OFF Action
Array [10]
Option: Function:
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC Brake
[27] Coast
[32] Set digital out A low
[33] Set digital out B low
[34] Set digital out C low
[35] Set digital out D low
[36] Set digital out E low
[37] Set digital out F low
[38] Set digital out A high
[39] Set digital out B high
[40] Set digital out C high
[41] Set digital out D high
[42] Set digital out E high
[43] Set digital out F high
[60] Reset Counter A
[61] Reset Counter B
[62] Counter A (up)
[63] Counter A (down)
[64] Counter B (up)
[65] Counter B (down)
[80] Sleep Mode
[90] Set ECB Bypass Mode
[91] Set ECB Drive Mode
[100] Reset Alarms
