176FA259.11
:ASTENER TORQUE: MM8 9.6 Nm (7FT-LB)
ASTENER TORQUE: M10 19 Nm (14FT-LB)
S/L2 92
T/L3 93
R/L1 91
W/T3 98
1
1 Ground terminals
Figure 4.5 Position of Ground Terminals IP00, Enclosure Type E
Electrical Installation
VLT
®
HVAC Drive FC 102
