Danfoss VLT HVAC Drive FC 102 - Page 47

2
7
U/T1 96
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
V/T2 97 W/T3 98 U/T1 96
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
V/T2 97 W/T3 98 U/T1 96
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
V/T2 97 W/T3 98
6
8, 9
4
3
1
5
130BA862.12
1) External temperature monitoring 6) Motor
2) AUX relay U V W
01 02 03 96 97 98
04 05 06 T1 T2 T3
3) NAMUR 7)
NAMUR fuse (see Table 4.23 for part numbers)
4) AUX fan 8)
Fan fuses (see Table 4.19 for part numbers)
100 101 102 103 9)
SMPS fuses (see Table 4.18 for part numbers)
L1 L2 L1 L2
5) Brake
-R +R
81 82
Figure 4.8 Inverter Cabinet, Enclosure Types F2 and F4
Electrical Installation
Instruction Manual
MG11F522 Danfoss A/S © 08/2014 All rights reserved. 45
4 4
