3.8.7 6-5* Analog Output 1
Parameters for configuring the scaling and limits for analog output 1, i.e., Terminal 42. Analog outputs are current outputs: 0/4–20 mA. Common terminal
(terminal 39) is the same terminal and has the same electrical potential for analog common and digital common connection. Resolution on analog output
is 12 bit.
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an analog current output. A motor current of 20 mA corre-
sponds to I
max
.
[0] * No operation
[100] Output frequency : 0–100 Hz, (0–20 mA)
[101] Reference : Minimum reference - Maximum reference, (0–20 mA)
[102] Feedback : -200% to +200% of par.20-14
Maximum Reference/Feedb.
, (0–20 mA)
[103] Motor current : 0 - Inverter Max. Current (par. 16-37), (0–20 mA)
[104] Torque rel to limit : 0 - Torque limit (par.4-16
Torque Limit Motor Mode
), (0–20 mA)
[105] Torq relate to rated : 0 - Motor rated torque, (0–20 mA)
[106] Power : 0 - Motor rated power, (0–20 mA)
[107] Speed : 0 - Speed High Limit (par.4-13
Motor Speed High Limit [RPM]
and par.4-14
Motor Speed High Limit
[Hz]
), (0–20 mA)
[113] Ext. Closed-loop 1 : 0–100%, (0–20 mA)
[114] Ext. Closed-loop 2 : 0–100%, (0–20 mA)
[115] Ext. Closed-loop 3 : 0–100%, (0–20 mA)
[130] Output freq. 4-20mA : 0–100 Hz
[131] Reference 4-20mA : Minimum Reference - Maximum Reference
[132] Feedback 4-20mA : -200% to +200% of par.20-14
Maximum Reference/Feedb.
[133] Motor cur. 4-20mA : 0 - Inverter Max. Current (par.16-37
Inv. Max. Current
)
[134] Torq.% lim 4-20 mA : 0 - Torque limit (par.4-16
Torque Limit Motor Mode
)
[135] Torq.% nom 4-20 mA : 0 - Motor rated torque
[136] Power 4-20mA : 0 - Motor rated power
[137] Speed 4-20mA : 0 - Speed High Limit (4-13 and 4-14)
[139] Bus ctrl. : 0–100%, (0–20 mA)
[140] Bus ctrl. 4-20 mA : 0 - 100%
[141] Bus ctrl t.o. : 0–100%, (0–20 mA)
[142] Bus ctrl 4-20mA t.o. : 0 - 100%
[143] Ext. Closed-loop 1 4-20 mA : 0 - 100%
[144] Ext. Closed-loop 2 4-20 mA : 0 - 100%
[145] Ext. Closed-loop 3 4-20 mA : 0 - 100%
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-86
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
