16-35 Inverter Thermal
Range: Function:
0 %* [0 - 100 %] View the percentage load on the inverter.
16-36 Inv. Nom. Current
Range: Function:
10.00 A* [0.01 - 10000.00 A] View the inverter nominal current, which should match the nameplate data on the connected motor.
The data is used for motor protection, calculating torque, etc.
16-37 Inv. Max. Current
Range: Function:
16.00 A* [0.01 - 10000.00 A] View the inverter maximum current, which should match the nameplate data on the connected
motor. The data is used for motor protection, calculating torque, etc.
16-38 SL Controller State
Range: Function:
0 N/A* [0 - 100 N/A] View the state of the event under execution by the SL controller.
16-39 Control Card Temp.
Range: Function:
0 C* [0 - 100 C]
16-40 Logging Buffer Full
Option: Function:
View whether the logging buffer is full (see par. 15-1*). The logging buffer will never be full when
par.15-13
Logging Mode
is set to
Log always
[0].
[0] * No
[1] Yes
3.16.5 16-5* Ref. & Feedb.
Parameters for reporting the reference and feedback input.
16-50 External Reference
Range: Function:
0.0 N/A* [-200.0 - 200.0 N/A] View the total reference, the sum of digital, analog, preset, bus and freeze references, plus catch-
up and slow-down.
16-52 Feedback [Unit]
Range: Function:
0.000 Proc-
essCtrlU-
nit*
[-999999.999 - 999999.999 Proc-
essCtrlUnit]
View value of resulting feedback value after processing of Feedback 1-3 (see par.16-54
Feedback
1 [Unit]
, par.16-55
Feedback 2 [Unit]
and par. 16-56) in the feedback manager.
See par. 20-0*
Feedback
.
The value is limited by settings in par. 20-13 and par. 20-14. Units as set in par.20-12
Reference/
Feedback Unit
.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-154
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3
