Danfoss VLT HVAC Series User Manual

16-53 Digi Pot Reference
Range: Function:
0.00 N/A* [-200.00 - 200.00 N/A] View the contribution of the digital potentiometer to the actual reference.
16-54 Feedback 1 [Unit]
Range: Function:
0.000 Proc-
essCtrlU-
nit*
[-999999.999 - 999999.999 Proc-
essCtrlUnit]
View value of Feedback 1, see par. 20-0* Feedback .
The value is limited by settings in par. and par. . Units as set in par.20-12
Reference/Feedback
Unit
.
16-55 Feedback 2 [Unit]
Range: Function:
0.000 Proc-
essCtrlU-
nit*
[-999999.999 - 999999.999 Proc-
essCtrlUnit]
View value of Feedback 2, see par. 20-0* Feedback .
The value is limited by settings in par. 20-13 and par. 20-14. Units as set in par.20-12
Reference/
Feedback Unit
.
16-56 Feedback 3 [Unit]
Range: Function:
0.000 Proc-
essCtrlU-
nit*
[-999999.999 - 999999.999 Proc-
essCtrlUnit]
View value of Feedback 3, see par. 20-0* Feedback .
The value is limited by settings in par.20-13
Minimum Reference/Feedb. and par.20-14 Maximum
Reference/Feedb.
. Units as set in par.20-12 Reference/Feedback Unit .
16-58 PID Output [%]
Range: Function:
0.0 %* [0.0 - 100.0 %] This parameter returns the Drive Closed-loop PID controller output value in percent.
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark 3-155
3

Danfoss VLT HVAC Series Specifications

General

Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Communication Interfaces	Profibus, Ethernet
Cooling Method	Forced convection
Ambient Temperature	-10°C to +40°C
Enclosure Rating	IP20, IP21, IP55
Output Voltage	0 - 100% of supply voltage
