[114] Ext. Closed-loop 2
[115] Ext. Closed-loop 3
[130] Output freq. 4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA
[134] Torq.% lim 4-20 mA
[135] Torq.% nom 4-20 mA
[136] Power 4-20mA
[137] Speed 4-20mA
[139] Bus ctrl.
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl t.o.
[142] Bus ctrl 4-20mA t.o.
[143] Ext. Closed-loop 1 4-20 mA
[144] Ext. Closed-loop 2 4-20 mA
[145] Ext. Closed-loop 3 4-20 mA
6-61 Terminal X30/8 Min. Scale
Range: Function:
0.00 %* [0.00 - 200.00 %] Scales the minimum output of the selected analog signal on terminal X30/8. Scale the minimum
value as a percentage of the maximum signal value, i.e., 0 mA (or 0 Hz) is desired at 25% of the
maximum output value and 25% is programmed. The value can never be higher than the corre-
sponding setting in par.6-62
Terminal X30/8 Max. Scale
if value is below 100%.
This parameter is active when option module MCB 101 is mounted in the adjustable frequency drive.
6-62 Terminal X30/8 Max. Scale
Range: Function:
100.00 %* [0.00 - 200.00 %] Scales the maximum output of the selected analog signal on terminal X30/8. Scale the value to the
desired maximum value of the current signal output. Scale the output to give a lower current than
20 mA at full scale or 20 mA at an output below 100% of the maximum signal value. If 20 mA is
the desired output current at a value between 0%–100% of the full-scale output, program the
percentage value in the parameter, i.e., 50% = 20 mA. If a current between 4 and 20 mA is desired
at maximum output (100%), calculate the percentage value as follows:
20
mA
/
desired
maximum
current
× 100%
i
.
e
. 10
mA
:
20
mA
10
mA
× 100% =200%
6-63 Terminal X30/8 Output Bus Control
Range: Function:
0.00 %* [0.00 - 100.00 %] Contains the value to apply to the output terminal when it is configured as [Bus Controlled].
6-64 Terminal X30/8 Output Timeout Preset
Range: Function:
0.00 %* [0.00 - 100.00 %] Contains the value to apply to the output terminal when it is configured as [Bus Controlled Timeout]
and timeout is detected.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-90
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3
