10-05 Readout Transmit Error Counter
Range: Function:
0 N/A* [0 - 255 N/A] View the number of CAN control transmission errors since the last power-up.
10-06 Readout Receive Error Counter
Range: Function:
0 N/A* [0 - 255 N/A] View the number of CAN control receipt errors since the last power-up.
10-07 Readout Bus Off Counter
Range: Function:
0 N/A* [0 - 255 N/A] View the number of Bus Off events since the last power-up.
3.11.3 10-1* DeviceNet
Parameters specific to the DeviceNet serial communication bus.
10-10 Process Data Type Selection
Option: Function:
Select the Instance (message) for data transmission. The instances available are dependent upon
the setting of par.8-10
Control Profile .
When par.8-10
Control Profile is set to [0] FC profile , par.10-10 Process Data Type Selection options
[0] and [1] are available.
When par.8-10
Control Profile is set to [5] ODVA , par.10-10 Process Data Type Selection options
[2] and [3] are available.
Instances 100/150 and 101/151 are Danfoss-specific. Instances 20/70 and 21/71 are ODVA-specific
AC drive profiles.
For guidelines in message selection, please refer to the DeviceNet Instruction Manual.
Note that a change to this parameter will be executed immediately.
[0] * INSTANCE 100/150
[1] INSTANCE 101/151
[2] INSTANCE 20/70
[3] INSTANCE 21/71
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark 3-111
3
