21-34 Ext. 2 Feedback Source
Option: Function:
See par.21-14
Ext. 1 Feedback Source
for details.
[0] * No function
[1] Analog input 53
[2] Analog input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog input X30/11
[8] Analog input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus feedback 1
[101] Bus feedback 2
[102] Bus feedback 3
21-35 Ext. 2 Setpoint
Range: Function:
0.000 Ex-
tPID2Unit*
[par. 21-31 - par. 21-32 Ex-
tPID2Unit]
See par.21-15
Ext. 1 Setpoint
for details.
21-37 Ext. 2 Reference [Unit]
Range: Function:
0.000 Ex-
tPID2Unit*
[-999999.999 - 999999.999 Ex-
tPID2Unit]
See par.21-17
Ext. 1 Reference [Unit]
,
Ext. 1 Reference [Unit]
, for details.
21-38 Ext. 2 Feedback [Unit]
Range: Function:
0.000 Ex-
tPID2Unit*
[-999999.999 - 999999.999 Ex-
tPID2Unit]
See par.21-18
Ext. 1 Feedback [Unit]
for details.
21-39 Ext. 2 Output [%]
Range: Function:
0 %* [0 - 100 %] See par.21-19
Ext. 1 Output [%]
for details.
3.19.6 21-4* Closed-loop 2 PID
Configure the Closed-loop 2 PID controller.
21-40 Ext. 2 Normal/Inverse Control
Option: Function:
See par.21-20
Ext. 1 Normal/Inverse Control
for details.
[0] * Normal
[1] Inverse
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3-191
